Поз.
Артикул
Описание
555
CONSOLE CAB SUSPENSION,REAR
555
CONSOLE CONSOLE TO FRAME,4 330046
556
SCREW BRACKET TO SIDE MEMBER
556
SCREW BRACKET TO SIDE MEMBER
557
NUT BRACKET TO SIDE MEMBER
557
NUT BRACKET TO SIDE MEMBER
557
NUT , Replaced By: N910113014001
558
SCREW BRACKET TO SIDE MEMBER M 14X1.5X35
558
SCREW , Replaced By: N308676014020
559
STRUT CAB MOUNTING,REAR (LEAF SPRING SUSPENSION)
559
STRUT , Replaced By: A6558910224, +002A6558910118
560
SHIM STRUT TO CONSOLE
561
LOCK WASHER FITTING TO BRACKET
562
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
562
SCREW , Replaced By: N308676012012
563
SPRING (LEAF SPRING),CAB SUSPENSION
564
BUSHING LEAF SPRING
565
TUBE LEAF SPRING, TO BE ADAPTED DURING ASSEMBLY
566
WASHER LEAF SPRING TO STRUT, DISCONTINUED,PART IS NO LONGER REQUIRED
567
SCREW SPRING TO STRUT, MODEL 416,417 FOR USE WITH MEDIUM-LENGTH MERCEDES-BENZ CAB5 215244
568
WASHER LEAF SPRING TO STRUT
569
NUT SUPPORT TO SIDE MEMBER
570
RAIL (CONNECTING RAIL), ON VEHICLES LESS DB CAB4 330047
570
RAIL (CONNECTING RAIL), ON VEHICLES LESS DB CAB4 330047
570
RAIL , Replaced By: A6558900222
570
RAIL , Replaced By: A3878900622
571
CYLINDRICAL PIN CONNECTING RAIL,4 330046
571
CYLINDRICAL PIN8X32 MM, ON VEHICLES LESS DB CAB
572
BUFFER RAIL STOP
572
BUFFER , Replaced By: A3878910323
573
MOUNTING CAB SUSPENSION,REAR
574
SCREW BUFFER AND MOUNTING TO RAIL
574
SCREW BUFFER AND MOUNTING TO RAIL M 8X20
575
SCREW FLEXIBLE METAL TUBE TO CONNECTOR AND TO COLLAR
575
SCREW , Replaced By: N304017008028
575
SCREW PIPE CLAMP
575
SCREW , Replaced By: N304017008021
576
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
577
WASHER BRACKET TO CROSS MEMBER
578
WASHER EXHAUST MUFFLER TO STRAP
578
WASHER , Replaced By: N000125008443
579
SHIM ,4 330046
580
MOUNTING CAB LOCKING MECHANISM
580
MOUNTING CAB MOUNTING,REAR,4 972621
580
MOUNTING , Replaced By: A3878918120
583
PIN BEARING BRACKET,4 972621
584
SPACER TUBE BEARING BRACKET
585
LOCK RING BEARING BRACKET,4 972621
586
SCREW SPACER TUBE TO MOUNTING
586
SCREW , Replaced By: N000960016251
587
NUT COMBINATION CYLINDER TO BEARING BRACKET
587
NUT COMBINATION CYLINDER TO BEARING BRACKET, Replaced By: N910113016002
588
PLATE MOUNTING AND RAIL TO LEAF SPRING
590
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
593
SCREW , Replaced By: N304017010055
593
SCREW , Replaced By: N304017010050
595
SHOCK ABSORBER (VIBRATION ABSORBER),CAB REAR SUSPENSION
595
SHOCK ABSORBER (VIBRATION ABSORBER),CAB REAR SUSPENSION
595
SHOCK ABSORBER , Replaced By: A0008911805
595
SHOCK ABSORBER CAB SUSPENSION,REAR,4 330046
595
SHOCK ABSORBER CAB SUSPENSION,REAR,4 330046
601
RUBBER MOUNTING
601
RUBBER MOUNTING , Replaced By: A0008910501
601
RUBBER MOUNTING ,4 330046
601
RUBBER MOUNTING , Replaced By: A0008910001
606
BUSHING ,4 330046
606
BUSHING , Replaced By: A0008910117
606
BUSHING
606
BUSHING , Replaced By: A0008910617
609
WASHER VIBRATION ABSORBER,4 330046
610
SPACER TUBE VIBRATION ABSORBER TO CONSOLE
612
SCREW SHOCK ABSORBER TO RAIL
612
SCREW , Replaced By: N000960018142
612
SCREW SHOCK ABSORBER TO CONSOLE M 14X55,4 330046
612
SCREW SHOCK ABSORBER TO CONSOLE
612
SCREW VIBRATION ABSORBER TO CONSOLE
612
SCREW14X1.5X148,4 330046
612
SCREW VIBRATION ABSORBER TO CONSOLE
612
SCREW , Replaced By: N000960018072
612
SCREW SHOCK ABSORBER TO CONSOLE M 14X130,4 330046
614
NUT BRACKET TO SIDE MEMBER
614
NUT INTERMEDIATE LEVER TO STEERING SUPPORT
614
NUT CAB ON CONSOLE AT FRAME
614
NUT INTERMEDIATE LEVER TO STEERING SUPPORT
614
NUT , Replaced By: N910113018004
614
NUT BRACKET TO SIDE MEMBER
614
NUT , Replaced By: N910113014001
616
SUPPORT EXPANSION TANK
616
SUPPORT , Replaced By: A3815001227
616
SUPPORT EXPANSION TANK,4 330046
616
CONSOLE , Replaced By: A3815000727
617
SCREW BRACKET TO SIDE MEMBER
617
SCREW BRACKET TO SIDE MEMBER M 14X1.5X35
617
SCREW BRACKET TO SIDE MEMBER M 14X1.5X35
617
SCREW , Replaced By: N308676014020
618
NUT BRACKET TO SIDE MEMBER
618
NUT , Replaced By: N910113014001
619
SCREW CONSOLE TO SIDE MEMBER
620
NUT SUPPORT TO SIDE MEMBER
624
FASTENER (CENTRAL LOCK) CAB LOCKING MECHANISM
624
FASTENER , Replaced By: A0008902389
624
FASTENER , Replaced By: A0008902389
627
ROD CENTRAL LOCK
630
PIN PULL TO FASTENER, 385.019 FOR USE WITH MEDIUM-LENGTH MERCEDES-BENZ CAB,385.068,069 ONLY VEHICLES HAVING NO MECEDES-BENZ CAB
633
WASHER BRACKET TO CROSS MEMBER
634
COTTER PIN LEVER TO ROD, Replaced By: N000094002060
636
CONSOLE CENTRAL LOCK
637
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
638
SCREW END PIECE TO EXHAUST PIPE M 10X25
639
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
640
NUT STRAP TO BRACKET
640
NUT , Replaced By: N910113010000
642
WASHER RADIATOR TO RUBBER MOUNTING
642
WASHER , Replaced By: N000125010532
645
BRACKET ROD THRU CAB
648
SEAL ROD THRU CAB
651
CLAMPING SLEEVE ROD TO BRACKET
999
JOINT BEARING , Replaced By: A0009817231
999
JOINT BEARING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A6208910017
999
JOINT BEARING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A6208910017
999
JOINT BEARING
999
LOCK , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A6208910017
999
SPACER WASHER , NOT USED
999
STIFFENING ,KB860814
999
CROSS MEMBER , Replaced By: A3853100436
999
COVER PLATE SHOCK ABSORBER
999
RUBBER BUFFER , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A6205860031
999
RUBBER BUFFER
999
PIN
999
ANGLE LEFT REINFORCEMENT
999
ANGLE RIGHT REINFORCEMENT
999
CROSS MEMBER , THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE, Replaced By: A3813120015
999
ANGLE LEFT TOP
999
ANGLE RIGHT TOP
999
WASHER , THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE, Replaced By: A6203170176
999
WASHER , Replaced By: N000125013008
999
SPRING , Replaced By: A3878910851, +001A3638910617
999
MOUNTING , Replaced By: A3878905303
999
MOUNTING , Replaced By: A3878905603
999
MOUNTING RETAINING ROPE
999
MOUNTING RETAINING ROPE
999
BUFFER , FIRST EXHAUST STOCK OF OLD PARTS,10/20 UP TO IDENT NO. 4 253140,50/60 UP TO IDENT NO. 4 257207, Replaced By: A3348910072
999
MOUNTING , NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IN REPAIR KIT, Replaced By: A3875860531
999
SHIM CAB TO FRAME
999
BUSHING , NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IN REPAIR KIT, Replaced By: A3875860531
999
LEVER , ON VEHICLES LESS DB CAB, Replaced By: A3878912856, +002A6208910017
999
LEVER , Replaced By: A3878912756, +002A6208910017
999
LEVER , Replaced By: A3878912856, +002A6208910017
999
SCREW PLUG STABILIZER
999
DISC SPRING , Replaced By: A3275045082, +001A3878912010
