Поз.
Артикул
Описание
12
TANK , Replaced By: A0004664502
12
TANK OIL
14
PIPETO 000 466 38 02
16
OIL DIPSTICK , Replaced By: A0004660867
16
OIL DIPSTICK
18
COVERTO 000 466 38 02
20
FILLER CAP
22
SEAL RINGTO 000 466 38 02
24
SEAL RING
26
FILTER CARRIERTO 000 466 38 02
28
BRACKET
30
FILTER
30
FILTER
34
SEAL RING , Replaced By: A0059970848
34
SEAL RINGTO 000 466 38 02
38
CONNECTORTO 000 466 38 02
42
NUTTO 000 466 38 02
46
CENTERING RINGTO 000 466 38 02
50
SPACER WASHERTO 000 466 38 02
50
WASHER , Replaced By: A9402680552
54
SPACER TUBETO 000 466 38 02
58
COVER PLATETO 000 466 38 02
62
RUBBER SLEEVETO 000 466 38 02
64
SCREW OIL TANK TO BRACKET
67
NUT , Replaced By: N913002006009
67
NUT OIL TANK TO BRACKET
70
BRACKET OIL TANK
75
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
78
HEXAGON HEAD BOLT BRACKET TO TRANSMISSION
85
LINE (DELIVERY LINE) FROM HIGH PRESSURE HOSE TO FITTING
90
GLAND , Replaced By: A0019901967
90
SEAL CONE LINE CONNECTION
94
UNION NUT LINE CONNECTION, Replaced By: N000000006239
94
UNION NUT LINE CONNECTION
94
UNION NUT , Replaced By: N915017012100
98
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
98
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
98
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
100
LINE , Replaced By: A0005516156
100
TUBE FROM HIGH PRESSURE HOSE TO STEERING
103
SEAL CONE LINE CONNECTION
103
GLAND , Replaced By: A0019901967
104
UNION NUT LINE CONNECTION, Replaced By: N000000006239
104
UNION NUT LINE CONNECTION
105
SCREW-IN FITTING DELIVERY LINE TO PUMP
110
HOSE , Replaced By: A6999974082
110
HOSE , NOT USED
110
HOSE , Replaced By: A3859971682
110
HOSE , Replaced By: A3439970582
114
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
114
CLAMP HOSE TO FITTING AND TO OIL TANK
120
LINE FROM STEERING TO OIL TANK
125
GLAND LINE CONNECTION
129
UNION NUT LINE CONNECTION
135
SCREW-IN FITTING RETURN, FROM STEERING TO OIL TANK
140
HOSE , Replaced By: A3859971582
140
HOSE RETURN, FROM STEERING TO OIL TANK, ORDER BY THE METER
145
CLAMP , Replaced By: N000000000667
145
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
150
LINE FROM OIL TANK TO HOSE, NOT USED
155
HOSE , Replaced By: A3859971582
155
HOSE RETURN, FROM STEERING TO OIL TANK, ORDER BY THE METER
160
CLAMP , Replaced By: N000000000667
160
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
162
LINE HOSE,CONNECTOR,STEERING
165
LINE (SUCTION LINE),FROM OIL TANK TO PUMP,5 227952
165
LINE FROM HOSE TO POWER STEERING PUMP
170
UNION NUT LINE CONNECTION, Replaced By: N000000006243
170
NUT LINE CONNECTION
174
GLAND , Replaced By: A0019901267
174
SEAL CONE LINE CONNECTION
180
BRACKET , Replaced By: A3812950440
180
BRACKET , EXHAUST STOCK OF OLD PARTS NUMBER FIRST UP TO CHASSIS 4 493018, Replaced By: A3812950440
180
BRACKET COMPRESSED AIR LINE TO FOUR-CIRCUIT PROTECTIVE VALVE,5 720506
185
BRACKET DELIVERY AND SUCTION LINES TO BRACKET AT FRAME
202
SCREW SUPPORT TO SIDE MEMBER
204
NUT SUPPORT TO SIDE MEMBER
206
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
208
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
210
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
210
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
212
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
214
SCREW DELIVERY AND SUCTION LINES TO ENGINE, TOP
216
NUT PUMP TO BRACKET
216
NUT , Replaced By: N913004006001
999
FILTER , Replaced By: A0004660604
999
SEALING CORD , Replaced By: A0059970848
999
NUT , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 764686 THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0019908151
999
SCREW , Replaced By: N000000001149
999
HOSE , Replaced By: A0009978152
999
HOSE , Replaced By: A0009978152
999
PROTECTIVE CAP
999
STEERING WHEEL ,4 430199, Replaced By: A3834640201, +001A0004640432
999
LINE HIGH PRESSURE HOSE,CONNECTOR,STEERING
999
STEERING SHAFT
999
RING STEERING SHAFT
999
WASHER , Replaced By: A3814620475
999
SLEEVE STEERING SHAFT
999
BOOT , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 456943, Replaced By: A3814621196
999
BRACKET , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 716042, Replaced By: A3874660940
999
LINE FROM PUMP TO HIGH PRESSURE HOSE
999
BRACKET OIL TANK
999
DRAG LINK , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A3834604605
999
DRAG LINKLEMFOERDER,4 459554
999
PITMAN ARM ,4 459554
999
LINE FROM RETURN LINE TO OIL TANK, 620.415 UP TO IDENT NO. 5 014668 620.416 UP TO IDENT NO. 5 000515 620.417 UP TO IDENT NO. 4 972023
999
LINE , NOT USED
999
BRACKET DELIVERY AND SUCTION LINES TO FRAME
999
HEXALOBULAR BOLT WIRE CABLE TO BRACKET
999
SCREW , Replaced By: A0029903712
999
WIRE STEERING BOX ASSEMBLY TO STEERING SUPPORT 600 MM
