Главная
›
Mercedes
›
TRUCK
›
LS 1622
›
386.052
›
54 ELECTRICAL EQUIPMENT AND INSTRUMENTS
›
001 ELECTRICAL SYSTEM,12V IL.3
Mercedes N007984006036 - Болт
LS 1622 386.052
54 ELECTRICAL EQUIPMENT AND INSTRUMENTS - 001 ELECTRICAL SYSTEM,12V IL.3
Поз.
Артикул
Описание
56
A6888307544
AIR DUCT BLOWER
59
A6928307061
HEATER UNIT
59
A6888357001
HEAT EXCHANGER
62
A3509877170
RUBBER SECTION , ORDER BY THE METER
65
A6928307008
BLOWER
65
A6888307108
BLOWER
68
A6888307042
FLAP LEFT
71
A6888307142
FLAP RIGHT
74
A6888337020
LINK
77
A0039885078
CLIP
80
A3318310034
SPRING
83
A3258310079
STRAP
86
N007984006036
SCREW
89
N000125006420
WASHER PLUG SOCKET TO BRACKET
92
N000934006006
NUT
95
N000127006203
LOCK WASHER EXTENSIBLE BRAKE VALVE TO CAB
98
N914127004221
SHEET METAL SCREW AIR DUCT TO BODY 4,8X25
101
N914127004217
SHEET METAL SCREW MUFFLER TO AIR INTAKE PIPE,INSIDE
104
A6889887025
TREENAIL BRACKET TO WINDOW LEVEL
107
A3768317998
SEAL AIR DUCT TO BODY
110
A6888317098
SEAL AIR DUCT TO BODY
