Mercedes N000931008281 - БОЛТ М8

OM 401 401.909 EURO 0 (OM 401)

20 ENGINE COOLING SYSTEM - 001 SUPPORT USED FOR COOLING WATER EXPANSION TANK

Поз.
Артикул
Описание
8
A3815000431
BRACKET
16
A3815000531
BRACKET
24
A3875001131
BRACKET
24
A3875000731
BRACKET , Replaced By: A3875001131
32
A3815000827
SUPPORT
40
A3875000927
SUPPORT , Replaced By: A3875001027
40
A3875000727
SUPPORT , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO ENGINE 154115, Replaced By: A3875000927
40
A3815000427
SUPPORT , Replaced By: A3875000727
40
A3875001027
SUPPORT
48
A3875001231
BRACKET
56
N000931008281
SCREW 3/2-WAY VALVE TO BRACKET M 8X105
64
N000933008145
SCREW CLAMP TO BRACKET AND TO PIPE
72
N912006008000
LOCK WASHER PARKING BRAKE VALVE TO WINDOW SILL
999
N000931008207
SCREW , Replaced By: N304014008007
999
A3875016120
BRACKET CABLE HARNESS MOUNTING, TO BE ADAPTED DURING ASSEMBLY
999
A3814291240
BRACKET
