Поз.
Артикул
Описание
127
BRACKET , EXHAUST STOCK OF OLD PARTS UP TO ENGINE 716010, Replaced By: A4420784741
127
BRACKET FUEL RETURN AND LEAK LINE
127
BRACKET , THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE, Replaced By: A4220780041
140
HEXAGON HEAD BOLT BRACKET TO SIDE MEMBER M12X1.5X40
140
SCREW BRACKET MOUNTING
166
BRACKET FUEL FILTER
170
SCREW ENGINE MOUNTING TO CONSOLE M 12X1.5X32
170
HEXAGON HEAD BOLT. SCREW FRONT EXHAUST PIPE TO BRACKET
170
SCREW CONSOLE TO FRAME SIDE MEMBER
170
SCREW BRACKET TO LEFT SIDE MEMBER
170
SCREW , Replaced By: N308676012012
170
SCREW , Replaced By: N308676012038
170
SCREW , Replaced By: N000961012051
170
SCREW , Replaced By: A0079903901
170
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
170
SCREW BEARING BRACKET TO FRAME
170
SCREW BRACKET TO TRANSMISSION
173
SUPPORT
173
SUPPORT
175
SCREW BRACKET WITH FUEL FILTER TO ENGINE
175
SCREW CONNECTING PIPE
180
LOCK WASHERROCKINGER TYP 59 G140,59 G150
225
BRACKET FUEL FILTER
225
BRACKET , Replaced By: A4030920840
245
INTERMEDIATE PIECE AT INJECTION PUMP
246
SEAL RING INJECTION PUMP
250
SCREW TORSION BAR TO SHACKLE,5 903514
250
SCREW TRANSMISSION
250
SCREW ,5 903514, Replaced By: N000960012353
252
HOSE FROM FILTER TO INJECTION PUMP
253
HOLLOW SCREW FUEL LINE TO FEED PUMP
254
SEAL RING INJECTION PUMP
255
LINE FUEL
255
LINE FUEL
400
HOLLOW SCREW TWO-WAY VALVE,CONNECTIONS: "11,12"
423
INTERMEDIATE PIECE AT INJECTION PUMP
429
HOLLOW SCREW FUEL LINE TO FEED PUMP
434
BANJO UNION FUEL LINES AND BREATHING
438
SEAL RING INJECTION PUMP
440
HOLLOW SCREW HEATING CONNECTION
440
HOLLOW SCREW FUEL LINE TO FEED PUMP
453
INTERMEDIATE PIECE AT INJECTION PUMP
453
INTERMEDIATE PIECE AT INJECTION PUMP
466
SCREENING NOZZLE HOLDER, TO BE ADAPTED DURING ASSEMBLY, Replaced By: A0119977782, +001A4030780074
466
HOSE LEAK LINE, ORDER BY THE METER
488
FITTING FROM INTAKE MANIFOLD TO VACUUM LINE, FROM IDENT NO.002799-360785
489
INTERMEDIATE PIECE AT INJECTION PUMP
489
INTERMEDIATE PIECE EXTENSIBLE BRAKE VALVE,CONNECTIONS: "10,20"
489
ADAPTER FITTING EXTENSIBLE BRAKE VALVE,CONNECTIONS: "10,20"
490
VALVE , Replaced By: A0000920610
490
VALVE FUEL FILTER
492
SEAL RING FUEL LINE TO FEED PUMP
504
BANJO UNION FUEL LINES AND BREATHING
504
BANJO UNION
504
BANJO UNION HOSE WIDTH, / I.D., 4/14 MM,K 169123
504
BANJO UNION , Replaced By: N000000000364
506
INTERMEDIATE PIECE (COLLECTING HOSE CONNECTION)
508
HOLLOW SCREW TWO-WAY VALVE,CONNECTIONS: "11,12"
509
HOLLOW SCREW FITTING INJECTION PUMP BLEEDING
509
HOLLOW SCREW FITTING LINE CONNECTION
590
SCREENING NOZZLE HOLDER, TO BE ADAPTED DURING ASSEMBLY, Replaced By: A0119977782, +001A4030780074
590
HOSE LEAK LINE, ORDER BY THE METER
601
SCREENING PLATE
615
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
615
SPRING WASHER , Replaced By: N000137008212
618
SCREW , Replaced By: N304017008039
618
SCREW , Replaced By: N304017008021
618
SCREW PIPE CLAMP
618
SCREW PROTECTIVE PLATE TO EXHAUST PIPE
620
SEAL RING FUEL LINE TO FEED PUMP
621
OIL LINE RIGHT
623
HOSE FROM FILTER TO INJECTION PUMP
623
HOSE LEAK LINE TO CYLINDER HEAD
626
HOSE FROM INJECTION PUMP TO FILTER
629
BANJO UNION FUEL TANK-TO-FUEL-PUMP FUEL LINE
632
HOSE FROM FILTER TO INJECTION PUMP
635
HOSE
636
FITTING LINE MOUNTING
638
PLUG
638
PLUG TO PLUG HYDRAULIC LINE
641
FITTING LINE MOUNTING
644
T-FITTING FUEL TANK SUPPORT
647
SEAL RING VALVE TO VALVE,K 025179
650
ADAPTER FITTING FROM FUEL PUMP TO FILTER
653
SCREW-IN FITTING RETURN, FROM STEERING TO OIL TANK
656
SCREW STOP TO BATTERY CASE
659
HOSE LEAK LINE, ORDER BY THE METER
662
HOSE LEAK LINE, ORDER BY THE METER
662
SCREENING NOZZLE HOLDER, TO BE ADAPTED DURING ASSEMBLY, Replaced By: A0119977782, +001A4030780074
665
BRACKET , Replaced By: A6205461343
665
BRACKET BATTERY CABLE TO CROSS MEMBER
668
CLAMP CABLE HARNESS MOUNTING
668
CLAMP , Replaced By: N916016010211
668
CLAMP , Replaced By: N000000001045
671
SCREW GROUND CONNECTION, SEE SA 28 101
671
SCREW COVER PLATE TO BRACKET
674
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
677
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
677
NUT , Replaced By: N913023006001
677
HEXAGON NUT. NUT LINE TO SIDE MEMBER
697
BANJO UNION FUEL TANK-TO-FUEL-PUMP FUEL LINE
698
HOLLOW SCREW TWO-WAY VALVE,CONNECTIONS: "11,12"
699
HOLLOW SCREW
702
INTERMEDIATE PIECE AT INJECTION PUMP
703
INTERMEDIATE PIECE AT INJECTION PUMP
705
SEAL RING INJECTION PUMP
706
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
708
SPRING WASHER CAB FLOOR
709
SCREW BEARING BRACKET TO FRAME
709
SCREW , Replaced By: N000961012051
711
FITTING LINE MOUNTING
712
PLUG
714
CLAMP
715
HOSE LEAK LINE, ORDER BY THE METER
717
HOSE FUEL LINE, ORDER BY THE METER
718
TS DOUBLE FITTING (PARTS KIT),LINE RUPTURE 4MM
719
SCREW PIPE CLAMP
719
SCREW , Replaced By: N304017008021
872
BANJO UNION FUEL LINES AND BREATHING
874
HOLLOW SCREW FUEL LINE TO FEED PUMP
895
FITTING RETURN
897
NUT. UNION NUT RETURN
946
VALVE FUEL FILTER
946
VALVE , Replaced By: A0000920610
952
SEAL RING INJECTION PUMP
999
SCREW , Replaced By: A4420740071
999
CLAMPING BRACKET FILTER HOUSING TO PUMP
999
PUMP , Replaced By: A0000911690, +001N915007008006
999
VALVE , Replaced By: A0000920410
999
FILTER ELEMENT , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0000922705
999
FILTER , Replaced By: A0000929301
999
FILTER , WITH METRIC THREAD 16 X 1.5, Replaced By: A0000929301
999
FILTER , WITH METRIC THREAD 16 X 1.5, Replaced By: A0000929301
999
FILTER , WITH INCH THREAD R 3/8", Replaced By: A0000900152
999
COVER , Replaced By: A4220900112
999
HOUSINGTO 001 477 14 01
999
FILTER ELEMENT , Replaced By: A3554700092
999
COVER , Replaced By: A4220900012
999
COVER , TO BE USED UP ON 001 477 71 01, Replaced By: A0000922808
999
COVER , EXHAUST STOCK OF OLD PARTS UP TO ENGINE 401,402,403 257485 404 005659 421,422,423 051822 424 000441, Replaced By: A4220900012
999
FELT TUBE ELEMENT. FILTER ELEMENT , Replaced By: A0000922705
999
FILTER ELEMENT , Replaced By: A3554700192
999
FILTER ELEMENT , Replaced By: A0000922705
999
FILTER ELEMENT , Replaced By: A0000922705
999
FILTER ELEMENT , Replaced By: A0000922705
999
FILTER ELEMENT , Replaced By: A3554700092
999
NUT
999
STUD
999
BANJO UNION , Replaced By: N915052004007
999
CLAMP , Replaced By: N916016010201
999
CLAMP , Replaced By: N916016010203
999
FITTING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0069971672
999
INJECTION PUMP , Replaced By: A0014778601
999
FUEL FILTER , Replaced By: A0014775001
999
FUEL FILTER , Replaced By: A0014775001
999
FUEL FILTER , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO CHASSIS 035153, Replaced By: A0010921801
999
FUEL FILTER , EXHAUST STOCK OF OLD PARTS NUMBER FIRST 035135, Replaced By: A0010921901
999
FUEL FILTER , Replaced By: A4220900252
999
FUEL FILTER , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0014774801
999
FUEL FILTER , Replaced By: A0014775701
999
FUEL FILTER , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A3244770001, +001A0004777215
999
FUEL FILTER , Replaced By: A0014778601
999
FUEL FILTER , Replaced By: A0014778601
999
FUEL FILTER , EXHAUST STOCK OF OLD PARTS UP TO ENGINE 401,402,403 257485 404 005659 421,422,423 051822 424 000441, Replaced By: A4220900152
999
FUEL FILTER , Replaced By: A4220900152
999
CLAMP , Replaced By: N916016011201
999
LOOM TIE , Replaced By: A0019978490
999
PLASTIC TUBE2X4MM, ORDER BY THE METER
999
HOSE , Replaced By: A0139976782
999
HOSE , Replaced By: A0119977782
999
HOSE , Replaced By: A0119977782
999
SEAL RING
999
HOLLOW SCREW , Replaced By: N915047010100
999
HOLLOW SCREW ,4 493018, Replaced By: N915047010100
999
BRACKET AT TRANSMISSION
999
BUSHING , Replaced By: A6673210153
999
FUEL FILTER , 628057
999
SPACER TUBE SHAPED HOSE ON AIR INTAKE PIPE
999
FILTER ELEMENT , Replaced By: A4220900051
999
FILTER ELEMENT , Replaced By: A4220900051
999
BRACKET , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A4030900140
999
SPACER TUBE , Replaced By: A3872680153
999
INTERMEDIATE PIECE , Replaced By: A4020700095
999
SCREENING , Replaced By: A4030700055
999
HOSE , Replaced By: A0119977782
999
HOSE , Replaced By: A0119977782
999
HOSE , Replaced By: A6154760326
999
BRACKET MULTI-STAGE FUEL FILTER
999
BRACKET FUEL LEAK LINE
999
BRACKET , Replaced By: A4030920540
999
BRACKET , Replaced By: A4220900041
999
BRACKET ,002101
999
BRACKET , Replaced By: A4030900741
999
BRACKET , Replaced By: A4230900341
999
ENGINE SUPPORT
999
LINE FROM PREFILTER TO FEED PUMP
999
LINE FROM INJECTION PUMP OVERFLOW LINE TO FUEL FILTER OVERFLOW VALVE
999
HOSE , Replaced By: A6154760326
999
BRACKET , NO LONGER AVAILABLE
999
BRACKET
