Поз.
Артикул
Описание
294
GEAR
294
GEAR , Replaced By: A7222720017
295
PIN
297
LOCK
298
SPRING
299
PAWL
305
LINKAGE
305
LINKAGE , Replaced By: A1152700665, +001A1152780517, +001A1159902140
306
ROLLER
307
PIN
308
THRUST WASHER
309
NEEDLE
310
ROLLER
311
LOCK PLATE LEVER TO BRACKET
312
WASHER
313
SPRING
318
BRACKET
319
SPRING WASHER LICENSE PLATE TO BRACKET
320
SCREW PUMP TO BRACKET
320
SCREW , Replaced By: N304017006016
325
GOVERNOR ,024695
327
FILTER
328
SEAL RING
328
SEAL RING
330
GEAR ,020936
331
DISC SPRING ,015266
335
TRANSMISSION CASE
335
TRANSMISSION CASE ,026754, Replaced By: A1152704911, +001A1152740628, +001N000933006077
335
TRANSMISSION CASE ,026754, Replaced By: A1152704911, +001A1152740628, +001N000933006077
335
TRANSMISSION CASE ,026754, Replaced By: A1152704911, +001A1152740628, +001N000933006077
335
TRANSMISSION CASE ,026754, Replaced By: A1152704911, +001A1152740628, +001N000933006077
335
TRANSMISSION CASE ,026754, Replaced By: A1152704911, +001A1152740648, +001N000933006077
338
BALL P.T.O. SHAFT
339
BALL
340
FITTING SLEEVE
341
CYLINDRICAL PIN
344
PLUG ,012878
346
PLUG ,018435
348
SEAL RINGTO 001 431 72 14
349
SCREW PLUG
350
BALL
351
SPRING ,012878
353
PIN ,010214
355
SEAL RING CHECK VALVE,CONNECTION "1",4 704213
356
SCREW PLUGROCKINGER TYP 59 G140,59 G150, Replaced By: N007604012105
357
SEAL RING
358
SCREW PLUG
362
SPEEDOMETER DRIVE
362
SPEEDOMETER DRIVE ,026754, Replaced By: A1152700327, +001A1152700342
365
CASE ,026755020936
368
SEAL RING
369
BALL
370
SPRING
371
SEAL RING SWITCH TO CASE COVER
372
SCREW PLUG
373
PISTON
375
SPRING WASHER LICENSE PLATE TO BRACKET
377
SCREW
378
SCREW COVER PLATE TO BRACKET
380
GROOVED BALL BEARING INTERMEDIATE BEARING
381
LOCK RING
381
LOCK STEERING KNUCKLE,TOP AND BOTTOM
382
SEAL RING
383
SPRING
384
PISTON
387
BRACKET
388
SPRING WASHER ALTERNATOR CONNECTION D+
389
SCREW HOOK TO BRACKET
389
SCREW MOUNTING OF INSTRUMENT PANEL
392
GASKET
392
GASKET , Replaced By: A1092710180
393
SPRING WASHER , Replaced By: N000137008212
393
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
394
SCREW SUPPORT TO FENDER
394
SCREW , Replaced By: N304017008018
395
COVER
396
SPRING
397
SPRING
400
PISTON
401
PISTON HOUSING,FRONT
402
SPRING HOUSING,FRONT
406
FLANGE
408
NUT
415
SCREW
416
SEAL RING
416
SEAL RING , Replaced By: A0079971448
416
SEAL RING , Replaced By: A0189971948
417
ECCENTRIC RING
850
GASKET KIT , Replaced By: A1152702201
850
GASKET KIT
999
SOLENOID
999
NEEDLE
999
SEAL RING ,000029
999
NEEDLE BEARING ,011777
999
LOCK ,022986
999
NEEDLE BEARING , Replaced By: A0059818110
999
NEEDLE BEARING ,043589
999
SEAL RING ,031534
999
HOSE ,049665
999
SEAL RING
999
HOSE FROM TRANSMISSION TO OIL COOLER
999
HOSE , FROM CHASSIS: 010 043070 015 042951 110 101088 115 046326
999
OUTER DISC , Replaced By: A1092721826
999
LOCK ,020254
999
GASKET , NO LONGER AVAILABLE INDIVIDUALLY
999
BOOT
999
BOOT , WITH 108 270 13 01: FROM TRANSMISSION 000001
999
OUTER DISC
999
OUTER DISC
999
OUTER DISC , 017664 EXCEPT FOR 015709-017194
999
OUTER DISC , WITH 108 270 13 01: FROM TRANSMISSION 000001
999
PIN AS REQUIRED 23 MM
999
PIN AS REQUIRED 24 MM
999
PIN 25 MM,AS REQUIRED
999
PIN 26 MM,AS REQUIRED
999
GROMMET OIL LINE TO CONVERTER HOUSING
999
CLAMP
999
GASKET KIT , Replaced By: A1142703301
999
OIL FILLER PIPE
999
LINE , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A1232701347, +001A1162700241, +001A1232700079, +001A1129970381, +001A1159975082
999
VALVE BODY ASSEMBLY
999
VALVE BODY ASSEMBLY
999
VALVE BODY ASSEMBLY , 007008 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
AUTOMATIC TRANSMISSION , PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
VALVE BODY ASSEMBLY
999
GASKET KIT , WITH 108 270 13 01: FROM TRANSMISSION 000001
999
THRUST PIN
999
GASKET KIT , Replaced By: A1152702001
999
REGULATOR VALVE
999
THRUST PIN
999
VALVE BODY ASSEMBLY ,000029, Replaced By: A1152701607, +002A1152701068
999
VALVE ,024694
999
PIN
999
VALVE , FROM TRANSMISSION: 115.000,002,010,015 024695-031534 115.100,102,103,110,112,115 019886-024365
999
VALVE ,019885
999
FLANGE , 017664 EXCEPT FOR 015709-017194, Replaced By: A1152704120, +001A1092720326, +002A1092722326
999
GOVERNOR ,024694
999
VALVE BODY ASSEMBLY
999
VALVE BODY ASSEMBLY
999
GASKET KIT ,019885
999
FLANGE , 014863 EXCEPT FOR 013132-014433, Replaced By: A1152704120, +001A1092720326, +002A1092722326
999
VALVE BODY ASSEMBLY
999
DRIVE SHAFT ,009363
999
VALVE BODY ASSEMBLY
999
FLANGE , 017665-023454 ALSO INSTALLED ON 015709-017194 NO LONGER AVAILABLE
999
DRIVE SHAFT , Replaced By: A1152705425, +001A0029942641
999
DRIVE SHAFT ,031315
999
PISTON ,019885
999
DRIVE SHAFT ,029735043589 NO LONGER AVAILABLE
999
DRIVE SHAFT ,031316
999
PLANETARY CARRIER , UP TO CHASSIS: 010 036484 015 034954 110 084330 115 038326
999
SPACER WASHER AS REQUIRED 0.2 MM
999
SPACER WASHER AS REQUIRED 0.5 MM
999
SPACER WASHER DRIVE SHAFT,AS REQUIRED 0.20 MM
999
SPACER WASHER 0.5 MM,AS REQUIRED
999
SPACER WASHER AS REQUIRED 0.2 MM
999
SPACER WASHER 0.5 MM,AS REQUIRED
999
ANNULUS , NO LONGER AVAILABLE INDIVIDUALLY
999
PLANET GEAR
999
PLANET GEAR
999
OUTER DISC , Replaced By: A1092722026
999
PISTON
999
ANNULUS , NO LONGER AVAILABLE INDIVIDUALLY
999
PIN
999
BOOT
999
SUN GEAR , NO LONGER AVAILABLE INDIVIDUALLY
999
BOOT
999
BOOT
999
FLANGE
999
GUARD PLATE , 013131 EXCEPT FOR 010364-010763
999
DISC SUPPORT ,017085
999
GUARD PLATE
999
GUARD PLATE
999
SEAL RING , Replaced By: A0119976447
999
CASE ,026754
999
DRIVE GEAR ,015265
999
DRIVE GEAR , FROM TRANSMISSION: 115.000,002,010,015 018035-026754 115.100,102,103,110,112,115 015266-020935 THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A1152741030, +001A1152700327
999
TUBE ,000029
999
GUIDE
999
SPACER WASHER
999
INTERMEDIATE PLATE ,024694
999
DETENT
999
LOCKING SHEET ,019885
999
INTERMEDIATE PLATE ,024694
999
SCREW , TO 115 270 12 11, 115 270 17 11
999
SHIFT VALVE
999
VALVE PART
999
SCREW , TO 115 270 27 11, 115 270 30 11, 115 270 39 11
999
SHIFT VALVE
999
SHIFT VALVE
999
VALVE PART
999
GASKET , Replaced By: A1152772980
999
INTERMEDIATE PLATE , TO 115 270 33 07
999
SHIFT VALVE
999
SHIFT VALVE
999
SHIFT VALVE
999
SHIFT VALVE
999
PISTON
999
VALVE PART
999
SHIFT VALVE
