Поз.
Артикул
Описание
15
COVERING , Replaced By: A1156911330
15
COVERING
17
PANELLING LEFT
35
SHEET METAL SCREW
37
WASHER
40
CLIP
43
PANELLING LEFT, STATE COLOR NUMBER WHEN ORDERING 089094 UP TO CHASSIS: 112 264038 ALSO INSTALLED ON 264678 EXCEPT FOR: 261782,262863,262889,262962,263157,263222,263274,263441,263442,263443,263696,263698,263710,263713, 263719,263734,263742,263745,263751,263752,263757,263758,263760-263764,263766,263768,263769,263773, 263790,263791,263797-263803,263807-263812,263815,263821-263824,263826-263832,263834-263839,263841- 263843,263845-263861,263863-263865,263868-263872,263874-263878,263880-263884,263886-263889,263891- 263954,263956-263970,263972-263979,263981-264037.
52
COVERING
55
COVERING
57
COVERING SHOCK ABSORBER TAKE-UP SHELL
60
COVERING
66
EDGE GUARD SECTION , Replaced By: A0009873272
69
LINING , STATE COLOR NUMBER WHEN ORDERING
71
STIFFENING , STATE COLOR NUMBER WHEN ORDERING
73
NUT , Replaced By: A0009900550
73
NUT
75
SCREW
81
BOW
83
BOW
85
BOW
87
BEARING , FROM CHASSIS:114.021 001842 114.022 002117 114.023 000001
89
CLIP
91
STIFFENING
122
COVERING , UP TO CHASSIS: 010 046179 ALSO INSTALLED ON 048604-049498 015 047269 ALSO INSTALLED ON 050446-051563 UP TO CHASSIS: 110,112 110847 ALSO INSTALLED ON 117451-120076 115 051165 ALSO INSTALLED ON 054537-055883
125
RIVET
127
GARNISH MOULDING RIGHT
127
GARNISH MOULDING LEFT
132
FASTENER BUTTON
132
FASTENER BUTTON. GROMMET , Replaced By: A0019882081
135
FASTENER BUTTON
135
FASTENER BUTTON
143
GARNISH MOULDING LEFT
146
FASTENER BUTTON
148
SCREW
150
PAD
151
FASTENER BUTTON
151
FASTENER BUTTON. GROMMET , Replaced By: A0019882081
153
NUT
155
SEAL RING
170
ORNAMENTAL COVER LEFT, 100000
191
FASTENER BUTTON , 041448 ALSO INSTALLED ON: 043393-044289
246
FASTENER BUTTON
248
FASTENER BUTTON
248
FASTENER BUTTON. GROMMET , Replaced By: A0019882081
999
WASHER COVERING TO CYCLONE AIR TRAP
999
SHEET METAL SCREW
999
SHEET METAL SCREW , UP TO CHASSIS: 010 046179 ALSO INSTALLED ON 048604-049498 015 047269 ALSO INSTALLED ON 050446-051563 UP TO CHASSIS: 110,112 110847 ALSO INSTALLED ON 117451-120076 115 051165 ALSO INSTALLED ON 054537-055883
999
SHEET METAL SCREW , Replaced By: N000000002062
999
SHEET METAL SCREW
999
SHEET METAL SCREW
999
SHEET METAL SCREW BRACKET TO CAB FLOOR
999
SHEET METAL SCREW
999
SCREW
999
SCREW
999
DRIP MOULDING RIGHT, FROM CHASSIS: 015 200001 110 400001 115 200001 005,017,105,107,108,117,119 000001
999
DRIP MOULDING LEFT, FROM CHASSIS: 015 200001 110 400001 115 200001 005,017,105,107,108,117,119 000001
999
ORNAMENTAL COVER RIGHT, FROM CHASSIS: 015 200001 110 400001 115 200001 005,017,105,107,108,117,119 000001
999
ORNAMENTAL COVER LEFT,AT REAR PILLAR
999
ORNAMENTAL COVER , Replaced By: A1156901689
999
ORNAMENTAL COVER , Replaced By: A1156901589
999
DRIP MOULDING RIGHT, FROM CHASSIS: 010 046180 EXCEPT FOR 048604-049498 015 047270 EXCEPT FOR 050446-051563 FROM CHASSIS: 110,112 110848 EXCEPT FOR 117451-120076 115 051166 EXCEPT FOR 054537-055883 UP TO CHASSIS: 015 200000 100,102,103,110,112 400000 115 200000
999
DRIP MOULDING LEFT, FROM CHASSIS: 010 046180 EXCEPT FOR 048604-049498 015 047270 EXCEPT FOR 050446-051563 FROM CHASSIS: 110,112 110848 EXCEPT FOR 117451-120076 115 051166 EXCEPT FOR 054537-055883 UP TO CHASSIS: 015 200000 100,102,103,110,112 400000 115 200000
999
ORNAMENTAL COVER OUTSIDE RIGHT, FROM CHASSIS: 015 200001 110 400001 115 200001 005,017,105,107,108,117,119 000001
999
ORNAMENTAL COVER RIGHT, FROM CHASSIS: 010 046180 EXCEPT FOR 048604-049498 015 047270 EXCEPT FOR 050446-051563 FROM CHASSIS: 110,112 110848 EXCEPT FOR 117451-120076 115 051166 EXCEPT FOR 054537-055883 UP TO CHASSIS: 015 200000 100,102,103,110,112 400000 115 200000
999
DRIP MOULDING RIGHT, UP TO CHASSIS: 010 046179 ALSO INSTALLED ON 048604-049498 015 047269 ALSO INSTALLED ON 050446-051563 UP TO CHASSIS: 110,112 110847 ALSO INSTALLED ON 117451-120076 115 051165 ALSO INSTALLED ON 054537-055883
999
DRIP MOULDING LEFT, UP TO CHASSIS: 010 046179 ALSO INSTALLED ON 048604-049498 015 047269 ALSO INSTALLED ON 050446-051563 UP TO CHASSIS: 110,112 110847 ALSO INSTALLED ON 117451-120076 115 051165 ALSO INSTALLED ON 054537-055883
999
DRIP MOULDING RIGHT, UP TO CHASSIS: 010 046179 ALSO INSTALLED ON 048604-049498 015 047269 ALSO INSTALLED ON 050446-051563 UP TO CHASSIS: 110,112 110847 ALSO INSTALLED ON 117451-120076 115 051165 ALSO INSTALLED ON 054537-055883
999
DRIP MOULDING LEFT, UP TO CHASSIS: 010 046179 ALSO INSTALLED ON 048604-049498 015 047269 ALSO INSTALLED ON 050446-051563 UP TO CHASSIS: 110,112 110847 ALSO INSTALLED ON 117451-120076 115 051165 ALSO INSTALLED ON 054537-055883
999
SEAL RIGHT, FROM CHASSIS: 015 200001 110 400001 115 200001 005,017,105,107,108,117,119 000001
999
PAD RIGHT
999
PAD LEFT
999
ORNAMENTAL COVER RIGHT, UP TO CHASSIS: 010 046179 ALSO INSTALLED ON 048604-049498 015 047269 ALSO INSTALLED ON 050446-051563 UP TO CHASSIS: 110,112 110847 ALSO INSTALLED ON 117451-120076 115 051165 ALSO INSTALLED ON 054537-055883
999
COVERING , FROM CHASSIS: 015 200001 110 400001 115 200001 005,017,105,107,108,117,119 000001
999
ORNAMENTAL COVER LEFT, UP TO CHASSIS: 010 046179 ALSO INSTALLED ON 048604-049498 015 047269 ALSO INSTALLED ON 050446-051563 UP TO CHASSIS: 110,112 110847 ALSO INSTALLED ON 117451-120076 115 051165 ALSO INSTALLED ON 054537-055883
999
PANELLING RIGHT
999
PANELLING , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO CHASSIS: 000,002,010 108565 015 139141 100,102,103,110,112 287056 115 146145, Replaced By: A1156921689
999
PANELLING , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO CHASSIS: 000,002,010 108565 015 139141 100,102,103,110,112 287056 115 146145, Replaced By: A1156921589
999
COVERING
999
COVERING , Replaced By: A1156911230
999
PANELLING RIGHT, STATE COLOR NUMBER WHEN ORDERING 089094 UP TO CHASSIS: 112 264038 ALSO INSTALLED ON 264678 EXCEPT FOR: 261782,262863,262889,262962,263157,263222,263274,263441,263442,263443,263696,263698,263710,263713, 263719,263734,263742,263745,263751,263752,263757,263758,263760-263764,263766,263768,263769,263773, 263790,263791,263797-263803,263807-263812,263815,263821-263824,263826-263832,263834-263839,263841- 263843,263845-263861,263863-263865,263868-263872,263874-263878,263880-263884,263886-263889,263891- 263954,263956-263970,263972-263979,263981-264037.
999
ORNAMENTAL COVER RIGHT, 200001
999
ORNAMENTAL COVER RIGHT, FROM CHASSIS: 015 200001 110 400001 115 200001 005,017,105,107,108,117,119 000001
999
PANELLING RIGHT, STATE COLOR NUMBER WHEN ORDERING 089093
999
PANELLING , STATE COLOR NUMBER WHEN ORDERING 089093
999
ORNAMENTAL COVER INSIDE RIGHT, FROM CHASSIS: 015 200001 110 400001 115 200001 005,017,105,107,108,117,119 000001
999
COVERING RIGHT
999
COVERING , Replaced By: A1156901030
999
HEADLINER , STATE COLOR NUMBER WHEN ORDERING
999
PANELLING RIGHT, STATE COLOR NUMBER WHEN ORDERING FROM CHASSIS: 112 264039 ALSO INSTALLED ON: 261782,262863,262889,262962,263157,263222,263274,263441,263442,263443,263696,263698,263710,263713, 263719,263734,263742,263745,263751,263752,263757,263758,263760-263764,263766,263768,263769,263773, 263790,263791,263797-263803,263807-263812,263815,263821-263824,263826-263832,263834-263839,263841- 263843,263845-263861,263863-263865,263868-263872,263874-263878,263880-263884,263886-263889,263891- 263954,263956-263970,263972-263979,263981-264037. EXCEPT FOR 264678 119 000001
999
PANELLING LEFT, STATE COLOR NUMBER WHEN ORDERING FROM CHASSIS: 112 264039 ALSO INSTALLED ON: 261782,262863,262889,262962,263157,263222,263274,263441,263442,263443,263696,263698,263710,263713, 263719,263734,263742,263745,263751,263752,263757,263758,263760-263764,263766,263768,263769,263773, 263790,263791,263797-263803,263807-263812,263815,263821-263824,263826-263832,263834-263839,263841- 263843,263845-263861,263863-263865,263868-263872,263874-263878,263880-263884,263886-263889,263891- 263954,263956-263970,263972-263979,263981-264037. EXCEPT FOR 264678 119 000001
999
EDGING RIGHT
999
GARNISH MOULDING RIGHT
999
EDGING LEFT
999
GARNISH MOULDING LEFT
999
PANELLING , Replaced By: A1156900569
999
GARNISH MOULDING RIGHT
999
CLIP , Replaced By: A0039881578
999
IMITATION LEATHER WHEELHOUSE 150X500 MM, STATE COLOR NUMBER WHEN ORDERING ORDER BY THE METER
999
SEALING CORD PAINT RUN-OFF HOLE IN REAR WINDOW OPENING, ORDER BY THE METER
999
IMITATION LEATHER 240X1050 MM, STATE COLOR NUMBER WHEN ORDERING ORDER BY THE METER
999
IMITATION LEATHER , Replaced By: A0029830086
999
IMITATION LEATHER , Replaced By: A0019837586
999
WASHER , FROM CHASSIS:113.043 002980 113.044 000001
999
STRIP LEFT REAR ROOF RAIL, ORDER BY THE METER
999
IMITATION LEATHER CENTRAL PILLAR 220X1000 MM, WHEN ORDERING STATE COLOR AND CHASSIS ORDER BY THE METER
999
STRIP
999
FOAM PLASTICS FRONT ROOF RAIL
999
FABRIC 150 X 500 MM, WHEN ORDERING,STATE COLOR,CHASSIS NO.,AND DIMENSIONS
999
FOAM PLASTICS , Replaced By: A0009833598
