Поз.
Артикул
Описание
61
HOSE ORDER BY THE METER
62
HOSE GREY/LIGHT BLUE, FROM CHASSIS: 073 103729, FEDERAL, ALSO INSTALLED ON: 102225,103388,103528,103535,103585,103608,103707,103715,103717,103722. 103836, CALIFORNIA, ALSO INSTALLED ON: 103522,103523,103542,103557,103582,103727,103741,103742,103758-103760,103778,103786,103791,103799, 103800,103803,103809,103810-103815,103819,103820,103822,103824,103830-103834. FROM CHASSIS: 023 100867
64
HOSE *** 30 MM
70
BRANCH-OFF FITTING
72
BRANCH-OFF FITTING
75
CLIP (HOSE LINE TO BRAKE BOOSTER)
75
CLIP , Replaced By: A1149880178
80
VALVE , FROM CHASSIS: 010 060996 110 152519
80
VALVE , Replaced By: A1168000378
82
CAP , FROM CHASSIS:114.010 031095 114.015 033617 UP TO CHASSIS: 114.010 053122 114.011 001283 114.015 061963 114.023 002937
85
TANK , FROM CHASSIS: 010 060996 110 152519
88
SEAL
89
RUBBER RING EMERGENCY LANTERN TO CAB
89
SEAL RING
94
GUIDE THRU FRONT PANEL PILLAR
98
GROMMET
101
HOSE *** 30 MM
105
HOSE FROM VACUUM SWITCH TO CIRCULATING-AIRFLAP-ELEMENT Y-SHAPE DISTRIBUTOR 600 MM
110
HOSE FROM VACUUM SWITCH TO CIRCULATING-AIRFLAP-ELEMENT Y-SHAPE DISTRIBUTOR 600 MM
110
HOSE , Replaced By: A0009976552
112
HOSE FROM VACUUM SWITCH TO CIRCULATING-AIRFLAP-ELEMENT Y-SHAPE DISTRIBUTOR 600 MM
114
BRANCH-OFF FITTING
116
CLAMP
118
RIVET
118
RIVET , Replaced By: A0009902292
999
HOSE MEDIUM GREEN, ORDER BY THE METER
999
HOSE FROM Y-DISTRIBUTOR TO AIR CONDITIONER CASE VACUUM ELEMENT,RIGHT
999
HOSE , Replaced By: A0089978582
999
HOSE FROM Y-DISTRIBUTOR TO AIR CONDITIONER CASE VACUUM ELEMENT,RIGHT
999
SCREW , Replaced By: A1009900663
999
HOLLOW SCREW , FROM CHASSIS:114.010 031095 114.015 033617 UP TO CHASSIS: 114.010 053122 114.011 001283 114.015 061963 114.023 002937
999
SEAL , Replaced By: A1238050298
999
THROTTLE , Replaced By: A1118005462
999
SWITCH , UP TO CHASSIS: 023 002726, Replaced By: A1148050073, +001A1148050036
999
VALVE , FROM CHASSIS:114.010 031095 114.015 033617 UP TO CHASSIS: 114.010 053122 114.011 001283 114.015 061963 114.023 002937
999
CONNECTOR , UP TO CHASSIS: 023 002726
999
CONNECTOR , Replaced By: A1128050203
999
ELEMENT , Replaced By: A0008000775
999
VALVE , Replaced By: A1168000378
999
TANK , FROM CHASSIS:114.005,007,008,015,017 120954 114.011 014765 114.060 001693 114.062 001710, Replaced By: A1158000419
999
TANK , Replaced By: A1158000519
999
TANK , Replaced By: A1158000519
999
DISTRIBUTOR , Replaced By: A1170780145
999
DISTRIBUTOR , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A1170780145
999
SEAL VACUUM SUPPLY TANK
999
NUT BALL PIVOT TO LEVER
999
TOOTHED WASHER MASKED STOP LAMP
