Mercedes N304017008034 - Болт крепления

230 G 460.241

27 AUTOMATIC TRANSMISSION - 001 MB AUTO TRANSMISS.ATTACHMENT PARTS IL.3

Поз.
Артикул
Описание
56
A4604701281
BRACKET
59
N000933006207
SCREW BRACKET ON LOAD SENSOR
62
N000125006449
WASHER COMPRESSED AIR LINE TO BRACKET
62
N000125006421
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
65
N913004006002
NUT , Replaced By: N913004006001
65
N913004006001
NUT PUMP TO BRACKET
68
N000933008153
SCREW , Replaced By: N304017008034
68
N304017008034
SCREW BRACKET TO CROSS CONNECTION STRUT
71
N009021008205
WASHER , Replaced By: N009021008213
71
N009021008213
WASHER BRACKET TO LEFT SIDE MEMBER
74
N912004008102
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
