Главная
›
Mercedes
›
CROSS-COUNTRY VEHICLE
›
240 GD
›
460.321
›
47 FUEL SYSTEM
›
001 ADDITIONAL FUEL TANK IL.1
Mercedes N000933005059 -
240 GD 460.321
47 FUEL SYSTEM - 001 ADDITIONAL FUEL TANK IL.1
Поз.
Артикул
Описание
9
A4605000018
RADIATOR COVERING
18
A4605050010
WIRE CABLE
27
A4605000031
BRACKET
36
N000933005036
SCREW SHUT-OFF VALVE TO BRACKET
45
N912004005103
LOCK WASHER BRACKET TO STEERING COLUMN END
54
A4605050140
BRACKET INSTRUMENT PANEL LOWER PART
63
N000933005059
SCREW BRACKET TO TAIL LAMP BRACKET
72
N000934005008
NUT TACHOGRAPH TO BRACKET
81
N912004005103
LOCK WASHER BRACKET TO STEERING COLUMN END
90
N000933006122
SCREW , Replaced By: N304017006034
90
N304017006034
SCREW COVER PLATE TO COVER PLATE M 6 X 10
99
N000934006007
NUT BALL PIVOT TO LEVER
108
N912004006102
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
117
A4609975381
GROMMET BOWDEN CABLE
126
A0019877625
PLASTIC SECTION CABLE HARNESS TO ROOF RAIL
