Поз.
Артикул
Описание
10
FRAME
10
FRAME , X 17211020070720
20
CONSOLE RIGHT
30
CONSOLE FRONT DAMPER TO LEFT FRAME
30
CONSOLE FRONT SHOCK ABSORBER TO FRAME,ON THE RIGHT
40
BRACKET RADIATOR MOUNTING
40
BRACKET RADIATOR MOUNTING
50
CONSOLE FRONT LEFT, X 17324820071029
60
BODY SUPPORT RIGHT
60
BODY SUPPORT LEFT
80
SUPPORT RIGHT
80
SUPPORT LEFT
90
BEARING BRACKET FRONT AXLE CONTROL ARM
90
BEARING BRACKET FRONT AXLE CONTROL ARM
100
STIFFENING BRAKE HOSE MOUNTING
110
BRACKET CONTROL ARM BRACKET,RIGHT FRONT
110
BRACKET CONTROL ARM BRACKET,FRONT LEFT
120
BRACKET CONTROL ARM BRACKET,REAR LEFT
120
BRACKET CONTROL ARM BRACKET,REAR RIGHT
130
SUPPORT REAR AXLE CONTROL ARM
140
BRACKET MOUNTING OF BRAKE HOSE,REAR AXLE
150
ANGLE EXHAUST MUFFLER TO FRAME
160
CONSOLE SUPPORT FOR REAR SPRING
180
THREADED BUSHING GROUND STRAP TO FRAME
190
BRACKET MOUNTING OF SENSOR CABLE ABS
200
BRACKET DIFFERENTIAL LOCK
210
SLEEVE BODY TO FRAME
210
SLEEVE
215
BUFFER PLATE BODY MOUNTING
220
CONSOLE TRANSMISSION MOUNTING
230
THREADED BUSHING GROUND CONNECTION
240
PLUG , Replaced By: A0009972020
250
EXPANSION PLUG IN FRONT PANEL PILLAR,OUTSIDE, FOR SLIDING ROOF HOSE
