Поз.
Артикул
Описание
11
FIRST AID BAG
11
FIRST AID BOX , Replaced By: A0008600250
12
RESERVOIR
18
FILLER CAP
21
CONNECTOR RESERVOIR FILLER CAP, 107.022,042 FROM PRODUCTION START FROM CHASSIS:107.023 009850 107.024 007850 107.043 011508 107.044 021172 ALSO INSTALLED ON: 021165,021170 UP TO CHASSIS: 107.022 005200, EXCEPT FOR: 005190-005192,005194-005199 107.023 012496 107.024 021803, EXCEPT FOR: 021794,021802 107.042 004221, EXCEPT FOR: 004213,004215-004218,004220 107.043 013576 107.044 047067, EXCEPT FOR: 047057,047061,067062,047064-047066
26
NOZZLE LEFT
27
NOZZLE RIGHT
30
CONNECTOR
33
SCREW
33
SHEET METAL SCREW , Replaced By: N000000002062
36
HOLDER
39
SCREW
39
SHEET METAL SCREW , Replaced By: N000000002062
42
WASHER , Replaced By: N000125004319
42
WASHER BRACKET TO SUPPORT
45
PUMP
45
PUMP , Replaced By: A0008693021
48
COMBINATION BOLT
67
HOSE RESERVOIR DE-AERATION,4 238841 ORDER BY THE METER
70
HOSE FROM RIGHT NOZZLE TO CHECK VALVE 900 MM
73
LOOM TIE TO MOUNT PLASTIC PIPING
73
LOOM TIE , Replaced By: A0019974390
76
LOOM TIE
