Поз.
Артикул
Описание
6
STARTING MOTORBOSCH, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
6
STARTING MOTOR , Replaced By: A0041519201
6
STARTING MOTOR24V, BOSCH
6
STARTING MOTOR24V, BOSCH
6
STARTING MOTOR12V, BOSCH, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
6
STARTING MOTOR , EXHAUST STOCK OF OLD PARTS UP TO ENGINE603.950000257, Replaced By: A0041513201
6
STARTING MOTOR , FIRST EXHAUST STOCK OF OLD PARTS UP TO ENGINE 911 10/50,20/&0 276888 911 12/52,22/62 022671 912 10/50,20/60 032279 912 12/52,22/62 009147, Replaced By: A0041513501
6
STARTING MOTOR , Replaced By: A0041513601
6
STARTING MOTOR , FIRST EXHAUST STOCK OF OLD PARTS UP TO ENGINE 12/94 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART, Replaced By: A0041517901
10
RING GEAR , Replaced By: A0001500131
10
GEAR SETTO A 004 151 71 01
10
GEARING PLANETARY GEAR TRAIN TO A 004 151 63 01
10
GEAR SET
18
GEARING PLANETARY GEAR TRAIN TO A 004 151 63 01
18
GEARING PLANETARY GEAR TRAIN TO A 004 151 71 01
18
GEARING , Replaced By: A0001500131
18
GEARING , Replaced By: A0001500131
18
COUPLING PART , Replaced By: A0001500631
24
PINIONTO A 004 151 71 01
24
PINION
24
PINIONTO A 004 151 63 01
38
BUSHING STARTER PINION
38
BUSHING , Replaced By: A0001518150
38
BUSHING STARTER PINION TO 005 151 01 01
74
NEEDLE BEARING , Replaced By: A0009812110
74
NEEDLE BEARING
170
EXCITER COIL
170
EXCITER COIL
170
EXCITER COILTO A 004 151 71 01
170
EXCITER COIL , Replaced By: A0001518655
194
BUSHING COMMUTATOR END SHIELD TO A 004 151 63 01, A 004 151 71 01
218
CARBON BRUSH SET
218
CARBON BRUSH SETTO A 004 151 63 01, A 004 151 71 01
230
SPRING CARBON BRUSHES TO A 004 151 63 01, A 004 151 71 01
242
SCREW BEARING COVER TO A 004 151 63 01/ 71 01
254
SOLENOID SWITCH
254
SOLENOID SWITCHTO A 004 151 63 01, A 004 151 71 01
254
SOLENOID SWITCH
266
BOLT. SCREW , Replaced By: A0049902712
326
REPAIR KIT ARMATURE MOUNTING TO A 004 151 63 01
328
SCREW STRAP TO BRACKET
328
COMBINATION BOLT STARTING MOTOR TO CRANKCASE M 10X90
330
SPRING WASHER STEERING COLUMN BRACKET TO CAB
332
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
334
NUT
334
NUT , Replaced By: N304032008006
336
MOUNTING BOW CABLE TO STARTING MOTOR,TERMINAL 50
338
SCREW ELECTRIC CABLE TO HORN
