Поз.
Артикул
Описание
10
AIR LINE HOT BOOST AIR PIPE ON EXHAUST TURBOCHARGER
25
HOSE CONNECTION OF CHARGING AIR PIPES
25
HOSE CHARGING-AIR-INTERCOOLER/TURBOCHARGER CONNECTION, Replaced By: A0015017982
38
PIPE CHARGING-AIR-INTERCOOLER/TURBOCHARGER CONNECTION
62
CHARGING AIR LINE CHARGE AIR COOLER TO ENGINE CIRCUIT'S COLD SIDE
65
HOSE CHARGE AIR COOLER TO ENGINE CIRCUIT'S COLD SIDE
72
CHARGING AIR LINE CONNECTION OF CHARGING AIR PIPES
95
CLAMP HOSE TO RADIATOR,PIPE ELBOW,AND WATER PUMP 82 - 105 X 15.8 MM
250
AIR LINE
260
AIR LINE
270
BRACKET BOOST AIR PIPE TO FRAME
280
BRACKET
290
BRACKET
300
BRACKET
310
PULL ROD LOAD SENSOR CONTROL, TO BE ADAPTED DURING ASSEMBLY
320
SCREW CONTROL LEVER TO INJECTION PUMP LEVER
320
BALL PIVOT CONTROL LEVER TO INJECTION PUMP LEVER, Replaced By: N000000004467
330
BALL STUD. BALL PIVOT TOP B10X4,5 MM
340
NUT SPRING-LOADED PUSH ROD
