Mercedes A9018801171 - Бампер задний

314, 308 CDI, 311 CDI, 313 CDI, 316 CDI 903.673 TO IDENT-NR. R337626

88 ATTACHMENT PARTS - 200 REAR BUMPER

Поз.
Артикул
Описание
5
A9018800571
REAR BUMPER FACE BAR. REAR BUMPER
5
A9018800971
REAR BUMPER FACE BAR BUMPER,CENTRAL, TO BE PAINTED PRIOR TO INSTALLATION
8
A9018850202
REAR BUMPER FACE BAR WITH STEP, CENTRE REAR
11
A9018800871
REAR BUMPER FACE BAR. REAR BUMPER RIGHT, TO BE PAINTED PRIOR TO INSTALLATION
11
A9018800371
REAR BUMPER FACE BAR LEFT
11
A9018800771
REAR BUMPER FACE BAR. REAR BUMPER LEFT, TO BE PAINTED PRIOR TO INSTALLATION
11
A9018801271
REAR BUMPER FACE BAR LEFT, TO BE PAINTED PRIOR TO INSTALLATION
11
A9018800471
REAR BUMPER FACE BAR. REAR BUMPER RIGHT
11
A9018801071
REAR BUMPER FACE BAR LEFT
11
A9018801371
REAR BUMPER FACE BAR RIGHT, TO BE PAINTED PRIOR TO INSTALLATION
11
A9018801171
REAR BUMPER RIGHT
17
A9018800414
BRACKET RIGHT
17
A9018800314
BRACKET LEFT
20
A9019910053
GUIDE
23
A0009902104
SCREW
26
A0009905592
RIVET FASTENING FOR LINING
50
A9015200031
RUNNING BOARD WHEELBASE:
60
N910105012001
HEXAGON HEAD BOLT. SCREW RUBBER BUFFER TO SUPPORT M 12X90
70
N913023012002
NUT BRACKET TO SIDE MEMBER M12X1.5
80
N910105010009
HEXAGON HEAD BOLT. SCREW BRACKET TO SIDE MEMBER M10X25
