Поз.
Артикул
Описание
5
SUPPORT AIR RESERVOIR
5
SUPPORT AIR RESERVOIR
10
BRACKET MOUNTING PARTS
15
BRACKET MOUNTING PARTS
20
BRACKET MOUNTING PARTS
25
BRACKET MOUNTING PARTS, SIMPLE PART-PLEASE HAVE SHOP MADE
30
BRACKET LINE MOUNTING
35
BRACKET MOUNTING PARTS 4MM
40
BRACKET LINE MOUNTING
43
BRACKET FRAME MOUNTED CABLE HARNESS TO CROSS MEMBER
45
BRACKET MOUNTING PARTS
50
CLAMP DELIVERY AND SUCTION LINES TO STEERING
50
CLAMP , Replaced By: A6739950001
55
TUBE , Replaced By: A0005516256
55
TUBE FROM HIGH PRESSURE HOSE TO STEERING, LENGTH AVAILABLE: 3000 MM
60
LINE AIR COMPRESSOR,PRESSURE REGULATOR, DEHYDRATOR 15X1.5 MM, LENGTH AVAILABLE: 3000 MM
60
TUBE , Replaced By: A0004291401
65
TUBE , Replaced By: A0004291401
65
LINE AIR COMPRESSOR,PRESSURE REGULATOR, DEHYDRATOR 15X1.5 MM, LENGTH AVAILABLE: 3000 MM
70
TUBE (COMPRESSED AIR LINE)
75
TUBE (COMPRESSED AIR LINE)
80
FITTING OIL LINE CONNECTION
85
CONNECTION FITTING ENGINE AIR COMPRESSOR,CONNECTION: "15"
90
SUPPORT UNDERRUN PROTECTION,LEFT
95
SCREW GUSSET PLATES AND REAR CROSS MEMBER TO SIDE MEMBERS
95
HEXAGON HEAD BOLT. SCREW BRACKET TO SIDE MEMBERM 12X1.5X30
95
HEXAGON HEAD BOLT. SCREW LOCK SPRING TO CROSS MEMBER M14X1.5X30
100
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
100
NUT BRACKET TO SIDE MEMBER M12X1.5
100
NUT BATTERY/APPARATUS SUPPORT TO FRAME SIDE MEMBER
