Поз.
Артикул
Описание
5
CONTROL UNIT ,A 087384A 800022, Replaced By: A0055450532, +001A0055454432
5
CONTROL UNIT , Replaced By: A0145454032
5
CONTROL UNIT , Replaced By: A0165457732
5
CONTROL UNIT TEMPOMAT (CRUISE CONTROL)
8
CODING PART TEMPOMAT (CRUISE CONTROL) CONTROL UNIT,A 800023
11
BRACKET CONTROL UNIT
11
BRACKET CONTROL UNIT
14
SHEET METAL SCREW BRACKET TO CAB FLOOR
17
LOCK , Replaced By: A0029941045
17
LOCK CONDENSER TO INTERIOR PLATE,LEFT OUTSIDE
17
LOCK PROTECTIVE GRILLE
20
SHEET METAL SCREW , Replaced By: N000000000459
20
SHEET METAL SCREW FUEL STRAINER SCREEN TO FUEL TANK
23
GROMMET CONTROL UNIT TO BRACKET
26
CONTROL UNIT ACTUATOR
27
PLUG HOUSING FINAL CONTROL ELEMENT, 8-POLE
28
COVERTO 006 545 81 28
29
PLUG PIN ADDITIONAL CABLE TO SERIES CABLE
41
NUT
44
LOCK
62
SCREW 3/2-WAY VALVE TO BRACKET
71
SPACER TUBE ACTUATOR TO BRACKET
71
SPACER ACTUATOR TO BRACKET, Replaced By: A0009923760
74
WASHER ACTUATOR TO BRACKET
74
WASHER AIR BAFFLE AND BRACKET TO RADIATOR
128
CABLE HARNESS , Replaced By: A1244407408
128
CABLE HARNESS TEMPOMAT (CRUISE CONTROL),B 238486
128
CABLE HARNESS TEMPOMAT (CRUISE CONTROL),F 143764
131
PIN BUSHING HOUSING CONTROL UNIT, 14-POLE
132
COVERTO 019 545 29 28
133
ROUND PIN BUSHING2.5 MM2
136
PIN BUSHING HOUSING 4-POLE
137
COVER
140
PIN BUSHING HOUSING SEAT HEATER RELAY, 8-POLE
141
COVERTO 006 545 81 28
144
PIN BUSHING HOUSING UNIPOLAR, HEAT SENSOR CONNECTION
145
ROUND PIN BUSHING WITH DETENT AND WITH CATCH FOR HOUSING 2.5 MM2
148
PLUG ADAPTERTO 014 545 04 28
149
PLUG ADAPTER. PLUG HEATING WATER VALVE, 4-POLE
150
PIN BUSHINGTO 000 821 19 26
153
GROMMET , ONLY WITH AIR CONDITIONING AUTOMATICS
156
CABLE HARNESS FROM STOP LIGHT SWITCH TO PLUG CONNECTION
156
CABLE HARNESS , Replaced By: A1245402408
159
PIN BUSHING HOUSING BIPOLAR
160
ROUND PIN BUSHING WITH DETENT AND WITH CATCH FOR HOUSING 2.5 MM2
163
PLUG ADAPTERTO 014 545 04 28
164
PLUG ADAPTER. PLUG HEATING WATER VALVE, 4-POLE
165
PIN BUSHINGTO 000 821 19 26
