Поз.
Артикул
Описание
8
COVERING ,F 044039
8
COVERING
11
STIFFENING RIGHT
11
STIFFENING LEFT
17
PLATE LEFT
17
PLATE RIGHT
23
SHACKLE
23
SHACKLE , Replaced By: A2103100360
26
PLATE LEFT
29
REINFORCEMENT RIGHT
29
REINFORCEMENT LEFT
35
PLATE TOP
38
PLATE BOTTOM
41
BRACKET BOTTOM
44
RIVET GEARING TO BACKREST FRAME 3 MM
47
GUIDE SIGNFUERSTUETZLAST U. ANHAENGERGEWICHT
47
GUIDE SIGN , Replaced By: A1245842217
47
GUIDE SIGN , Replaced By: A1245843917
47
GUIDE SIGN , Replaced By: A1245843121
50
MOUNTING MATERIAL (PARTS KIT)
53
NUT STRAP TO BRACKET
56
SCREW
59
SCREW , Replaced By: N910106010031
59
SCREW HYDROPNEUMATIC SPRING LEG TO REAR AXLE
62
WASHER STRUT TO CROSS MEMBER
65
SCREWM 8X18
68
BALL HEAD , Replaced By: A1243100556
68
BALL HEAD , Replaced By: A1243100356
68
BALL HEAD
71
CAP
74
LOCKTO 124 310 01 56
74
PADLOCK
77
PROTECTIVE WRAPPER
77
PROTECTIVE WRAPPER , Replaced By: A1245850103
80
GUIDE SIGN FOR DETACHABLE BALL HEAD
80
GUIDE SIGN , Replaced By: A1245841417
80
GUIDE SIGN , Replaced By: A1245847521
