Поз.
Артикул
Описание
5
INJECTION PUMP ,960 011122 960 12/52,22/62 017955 AUSTRIA EXCEPT FOR 017374,017375,017411,017796-017798,017823-017831,017854. 963 12/52,22/62 000846 AUSTRIA EXCEPT FOR 000824-000826,000830,000831. FROM ENGINE SEE SA 12461/12 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
8
PRESSURE VALVE HOLDER
11
SEAL RING101
11
SEAL RING , Replaced By: A0179974148
14
SPRING
17
SEAL RING PRESSURE VALVE HOLDER
20
VALVE
23
PUMP ELEMENT
26
SLEEVE , Replaced By: A0000742332
26
SLEEVE , Replaced By: A0000741832
26
SLEEVE
29
CLAMPING PIECE
32
SPRING
35
TAPPET CYLINDER NO.1
35
TAPPET
35
TAPPET CYLINDER NO.2-5
38
ROLLER14.52 MM
38
ROLLER14.88 MM
38
ROLLER14.76 MM
38
ROLLER14.94 MM
38
ROLLER15.54 MM
38
ROLLER15.48 MM
38
ROLLER14.64 MM
38
ROLLER15.00 MM
38
ROLLER14.82 MM
38
ROLLER15.24 MM
38
ROLLER15.12 MM
38
ROLLER15.06 MM
38
ROLLER15.18 MM
38
ROLLER14.70 MM
38
ROLLER15.36 MM
38
ROLLER15.84 MM
38
ROLLER14.40 MM
38
ROLLER15.72 MM
38
ROLLER15.42 MM
38
ROLLER AS REQUIRED 15.60 MM
38
ROLLER AS REQUIRED 15.30 MM
38
ROLLER15.96 MM
50
SHACKLE
62
SCREW PLUG , Replaced By: N000908012009
62
SCREW PLUG, FILLING. SCREW PLUG 3/2-WAY VALVE,CONNECTION: "10"
68
SCREW PLUG
71
SEAL RING SWITCH TO CASE COVER
74
SCREW PLUG, FILLING. SCREW PLUG 3/2-WAY VALVE,CONNECTION: "10"
74
SCREW PLUG , Replaced By: N000908012009
77
SEAL RING
86
SPRING
89
SPRING
95
SEAL RING SCREW PLUG
104
STUD
110
SEAL RING
122
SEAL RING
125
GASKET
125
GASKET LATERAL, ONLY IN CONJUNCTION WITH SHEET-METAL COVER
140
VACUUM BOX , Replaced By: A0000704653
140
VACUUM BOX , USE PARTS WITH OLD PART NUMBER ONLY WHERE SUCH PARTS ARE ALREDY INSTALLED, Replaced By: A0000704653
140
VACUUM BOX STOP BOX
143
BRACKET STOP BOX
146
SCREW
146
SCREW , Replaced By: A0019902312
149
SEAL RING
180
GASKET , Replaced By: A0000911780
180
GASKET FUEL PUMP
183
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
186
NUT BATTERY MOUNTING
186
NUT CYLINDER TO BRACKET TO0002902112
201
SOLENOID , Replaced By: A0000744688
201
SOLENOID OPERATING MAGNET ELECTRONIC IDLING CONTROL TO 602 070 05 01,602 070 34 01
207
SEAL RING
213
BRACKET
216
SCREW (OPERATING MAGNET)
228
GASKET COVER TO GOVERNOR HOUSING TO 602 070 43 01
