Поз.
Артикул
Описание
12
UNION NUT BUTT SCREW CONNECTION
12
UNION NUT LINE CONNECTION
18
GLAND LINE CONNECTION
48
BANJO UNION HOSE WIDTH, / I.D., 9/16 MM
48
BANJO UNION , Replaced By: N915052009009
50
CONNECTOR BRAKE POWER REGULATOR,CONNECTION: "30"
50
CONNECTOR 75 DEGREES
66
BANJO UNION HOSE WIDTH, / I.D., 6/12 MM
66
BANJO UNION HOSE WIDTH, / I.D., 6/16 MM
111
FITTING AIR RESERVOIR,CONNECTION: "13"
111
FITTING AIR DEHYDRATOR,CONNECTION: "10",5 350368
111
FITTING AIR DEHYDRATOR,CONNECTION: "10",5 433280
114
FITTING AIR DEHYDRATOR,CONNECTION: "10",5 350368
114
ELBOW FITTING ,5 433281
114
ELBOW FITTING ANTI-FREEZE DEVICE,CONNECTION: "10", BUTT CONNECTION
115
NUT CHECK VALVE TO AIR RESERVOIR
117
CONNECTION FITTING ENGINE AIR COMPRESSOR,CONNECTION: "15"
120
THRUST RING CHECK VALVE TO AIR RESERVOIR
120
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
126
O-RING CHECK VALVE TO AIR RESERVOIR
132
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
138
THRUST RING CHECK VALVE TO AIR RESERVOIR
138
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
144
O-RING CHECK VALVE TO AIR RESERVOIR
150
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
156
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
158
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
162
HOLLOW SCREW HEATING CONNECTION
168
SEAL RING LINE CONNECTION
999
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
999
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
999
FILTER ELEMENT , Replaced By: A0004293795
999
CONNECTOR 90 DEG. OFFSET
999
AIR CLEANERBOSCH
999
AIR CLEANER , Replaced By: A0004293695
999
REPAIR KIT PRESSURE REGULATOR BOSCH,241
999
ANTI-FREEZE DEVICEWABCO
999
RESERVOIR , Replaced By: A0034321201
999
RESERVOIR ,5 934167, Replaced By: A0034321401
999
FILTER , Replaced By: A0004291297
999
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
999
RESERVOIR , Replaced By: A0024311602, +001A0004317833
999
VALVE , Replaced By: A0034315006
999
RESERVOIR ,5 934167, Replaced By: A0034320601
999
T-FITTING PRESSURE RELIEF VALVE,CONNECTION: "10"
999
VALVE , Replaced By: A0024319106
999
RESERVOIR20L,246 MM,12.5 BAR
999
RESERVOIR ,5 563826
999
HOSE PRESSURE REGULATOR,CONNECTION: "30", ORDER BY THE METER
999
STRAP AIR RESERVOIR TO BRACKET
999
BRACKET AIR RESERVOIR TO FRAME
999
STRAP FRONT AIR RESERVOIR,RIGHT
999
STRAP AIR RESERVOIR,FOUR-CIRCUIT PROTECTIVE VALVE
999
BRACKET AIR CLEANER
999
STRAP SPRING-LOADED BRAKE AIR RESERVOIR, Replaced By: A6554900942
999
STRAP AIR RESERVOIR TO BRACKET
999
STRAP ANTI-FREEZE DEVICE
999
STRAP AIR RESERVOIR III,5 088362
