Поз.
Артикул
Описание
3
ELECTRIC CABLE FROM RELAY TO FUSE BOX
3
ELECTRIC CABLE FROM RELAY TO FUSE BOX
12
PIN BUSHING HOUSING 5-POLE
16
PIN BUSHING HOUSING 4-POLE
21
PIN BUSHING HOUSING UNIPOLAR
30
PLUG FROM CHASSIS/CAB CONNECTION POINT TO TACHOGRAPH 2.5 MM2
39
SOCKET. PIN BUSHING LESS DETENT,BUT WITH CATCH FOR HOUSING 2,5 MM2
39
PIN BUSHING , Replaced By: A0075458226
48
LOOM TIE LINE MOUNTING 280 MM
66
PLUG FROM CHASSIS/CAB CONNECTION POINT TO TACHOGRAPH 2.5 MM2
84
RELAYA33
84
RELAY , Replaced By: A0035459605
84
RELAY , Replaced By: A0035459605
84
RELAYA33, Replaced By: A0009822123
102
CONTACTOR RADIOPHONE BATTERY
106
FUSEA8
106
FUSE , Replaced By: N072581008101
110
FUSE CONTACTOR
115
BRACKET RELAY
122
BRACKET FUSE
129
SCREW BRACKET TO TAIL LAMP BRACKET
138
LOCK WASHER T-FITTING TO BRACKET
147
NUT , Replaced By: N304032005005
147
NUT IN CASE OF SUBSEQUENT INSTALLATION
156
SCREW COVER PLATE TO BRACKET
165
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
174
GROMMET FUEL LINE THRU FRAME SIDE MEMBER 38/30 MM
183
PIN BUSHING HOUSING BIPOLAR
192
PLUG HOUSING 4-POLE
201
BRACKET BUZZER SIGNAL SYSTEM
210
SCREW END PIECE TO EXHAUST PIPE M 10X25
219
NUT STRAP TO BRACKET
219
NUT , Replaced By: N910113010000
228
PLUG SOCKET BUZZER
237
SCREW , Replaced By: N000000001933
237
SCREW FUSE BOX TO SIDE MEMBER,5 097182
246
LOCK WASHER T-FITTING TO BRACKET
255
SHEET METAL SCREW BLIND PLUG SOCKET
999
CAP BUZZER
999
ELECTRIC CABLE FROM SWITCH BOX PLUG-CONNECTION TO RELAY
999
SCREW , Replaced By: N304017006016
999
SCREW PUMP TO BRACKET
