Поз.
Артикул
Описание
7
AIR CLEANER
12
GASKET
19
FASTENER AIR CLEANER BOWL
19
FASTENER , Replaced By: A0010940055
25
INTAKE PIPE
33
LOOM TIE
41
SCREW , Replaced By: A0029903712
50
NUT AIR CLEANER ELEMENT, Replaced By: N000000004429
71
INTAKE PIPE
101
CLAMP HOSE TO CYCLONE PRE-SEPARATOR
101
CLAMP AIR INTAKE PIPE TO THROTTLE HOUSING
113
CLAMP PRESSURE REGULATOR BREATHING
152
CLAMP
168
SCREW , Replaced By: N304017008034
175
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
183
NUT , Replaced By: N304032008006
191
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
199
SCREW IGNITION COIL TO BRACKET
206
STRUT
213
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
220
SCREW IGNITION COIL TO BRACKET
227
CAGE CLIP WITH NUT M 8. NUT RETAINER COVERING TO COVER PLATE
999
CLAMP , Replaced By: A0039975990
999
FILTER ELEMENT
999
FILTER ELEMENT ,184086 EXCEPT FOR 050 192297 AB IDENT-NO. SIEHE MOTORLISTE 006
999
INTAKE PIPE
999
GASKET OUTSIDE MANN & HUMMEL
999
FASTENER
