Поз.
Артикул
Описание
3
THROTTLE HOUSING PARTS KIT,K 181318N 817421 - N 825202
6
VALVE PARTS KIT,K 181318N 817421 - N 825202
9
BUSHING THROTTLE VALVE SHAFT
12
LEVER EXHAUST-BRAKE THROTTLE VALVE
12
LEVER , Replaced By: A3661400232, +001N913017006000, +001N914126006025
15
BALL PIVOT BOTTOM B13X5 MM
18
SCREW LONGITUDINAL DIFFERENTIAL LOCK VALVE TO BRACKET,5 963747
21
NUT BALL PIVOT TO LEVER
24
CYLINDER , Replaced By: A0004303026
24
CYLINDER , Replaced By: A0004304926
24
CYLINDER INTERMEDIATE SPEED STOP
24
CYLINDER
24
CYLINDER INCREASE IN NUMBER OF REVOLUTIONS KNORR
25
BUSHING"WABCO"
25
BUSHING , Replaced By: A0004340850
25
BUSHINGTO 000 430 30 26/32 26
28
REPAIR KITTO 000 430 48 26,KNORR
28
REPAIR KIT SHIFTING CYLINDER TO KNORR, SZ 1130 I/74963,000 430 3026
30
NUT , Replaced By: N304035008001
30
NUT
33
BALL SOCKET
33
BALL SOCKET SHIFTING CYLINDER TO SHIFT LEVER
36
SECURING CLIP. CIRCLIP
39
PIN CYLINDER TO BRACKET
39
PIN INTERMEDIATE SPEED STOP
39
PIN , Replaced By: A4421440574
42
WASHER EXHAUST MUFFLER TO STRAP
42
WASHER INTERMEDIATE SPEED STOP
42
WASHER , Replaced By: N000125008443
45
NUT , Replaced By: N913004008001
45
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
45
NUT
48
WASHER SUPPORTING RAIL TO SUPPORT,5 429712
51
NUT
54
BRACKET , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. K 077169/N 817421 - 825202, Replaced By: A3661440440
54
BRACKET POWER CYLINDER, TO BE ADAPTED DURING ASSEMBLY
57
SCREW BRACKET TO THROTTLE HOUSING M 8X16
60
EXHAUST PIPE FRONT,FRONT PART
63
CONNECTOR FRONT,FRONT PART
63
CONNECTOR FRONT,FRONT PART,5 195195
63
CONNECTOR FRONT,FRONT PART,5 195196
66
EXHAUST PIPE FRONT,FRONT PART,5 195196
66
EXHAUST PIPE FRONT,FRONT PART,5 195195
69
BRACKET FRONT EXHAUST PIPE
72
FLEXIBLE METAL TUBE CONNECTOR
75
COLLAR EXHAUST LINE FLEXIBLE METAL TUBE
78
CLAMP FLEXIBLE METAL TUBE TO CONNECTOR AND TO COLLAR
81
SCREW BRACKET TO SIDE MEMBER
81
SCREW , Replaced By: N304017008040
84
NUT , Replaced By: N913004008001
84
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
87
EXHAUST PIPE FRONT
87
EXHAUST PIPE FRONT,REAR PART,5 191852
87
EXHAUST PIPE FRONT,REAR PART
87
EXHAUST PIPE FRONT,REAR PART
126
BRACKET EXHAUST PIPE SUSPENSION
129
SCREW BRACKET TO SIDE MEMBER
129
SCREW , Replaced By: N304017010002
132
NUT , Replaced By: N910113010000
132
NUT STRAP TO BRACKET
135
BRACKET EXHAUST PIPE SUSPENSION
138
SCREW PIPE CLAMP
138
SCREW , Replaced By: N304017008021
141
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
141
NUT , Replaced By: N913004008001
144
BRACKET TAIL PIPE
147
BRACKET BRACKET TO EXHAUST PIPE BRACKET
150
SCREW BRACKET TO SPRING BRACKET AND TO CROSS MEMBER,5 953233K 027550
153
NUT , Replaced By: N913004008001
153
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
156
CLAMP FLEXIBLE METAL TUBE TO EXHAUST PIPE
159
SCREW BRACKET TO SIDE MEMBER
159
SCREW , Replaced By: N304017010002
162
NUT STRAP TO BRACKET
162
NUT , Replaced By: N910113010000
999
DAMPING PAD PARTICLE FILTER
999
BRACKET RUBBER BUFFER,5 129244
999
BRACKET EXHAUST PIPE, TO BE ADAPTED DURING ASSEMBLY
999
SUPPORT TAIL PIPE
999
BRACKET , Replaced By: A3834927941
999
SUPPORT REAR EXHAUST MUFFLER
999
CLAMP LINE MOUNTING
