Поз.
Артикул
Описание
167
LINE FROM FITTING TO VALVE 6X1 MM, LENGTH AVAILABLE 3000 MM
170
UNION NUT
173
GLAND , Replaced By: A0019901667
173
SEAL CONE
176
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
179
HOSE FROM HYDRAULIC LINE TO CYLINDER
179
HOSE FROM HYDRAULIC LINE TO CYLINDER
182
UNION NUT
185
GLAND , Replaced By: A0019901667
185
SEAL CONE
188
T-FITTING EXHAUST-BRAKE POWER CYLINDER
188
T-FITTING EXHAUST-BRAKE POWER CYLINDER
194
ELBOW FITTING FROM PUMP TO CYLINDER, Replaced By: N000000006197
194
ELBOW FITTING FROM PUMP TO CYLINDER, Replaced By: N000000006197
194
ELBOW FITTING FROM PUMP TO CYLINDER, Replaced By: N000000006197
194
ELBOW FITTING FROM PUMP TO CYLINDER, Replaced By: N000000006197
200
ANGLE LINE MOUNTING
203
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT
206
BRACKET , Replaced By: A3604292940
206
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT
212
BRACKET SUCTION LINE
218
SCREW , Replaced By: N304017008034
218
SCREW BRACKET TO CROSS CONNECTION STRUT
221
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
221
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
221
NUT , Replaced By: N913004008001
224
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X35
224
SCREW , Replaced By: N308676012026
227
NUT SUPPORT TO SIDE MEMBER
230
CLAMP LINE MOUNTING
230
CLAMP LINE MOUNTING
233
SCREW , Replaced By: N304017006016
233
SCREW PUMP TO BRACKET
236
NUT PUMP TO BRACKET
236
NUT , Replaced By: N913004006001
239
HOSE FROM HYDRAUL.CYLINDER TO TRANSMISSIONSHIFTING-ROD PAWL
239
HOSE FROM HAND PUMP TO HYDRAULIC CYLINDER 2820MM,5 126157 10/50 UP TO IDENT NO. 5 202493 20/60 UP TO IDENT NO. 5 202933
239
HOSE FROM HAND PUMP TO HYDRAULIC CYLINDER
239
HOSE FROM HYDRAUL.CYLINDER TO TRANSMISSIONSHIFTING-ROD PAWL,5 942826
242
UNION NUT
245
GLAND , Replaced By: A0019901667
245
SEAL CONE
248
ELBOW FITTING FROM PUMP TO CYLINDER, Replaced By: N000000006197
251
FITTING 3/2-WAY VALVE,CONNECTION: "30"
254
SEAL RING , Replaced By: N007603010110
254
SEAL RING PNEUMATIC VALVE
257
LOOM TIE LINE MOUNTING
257
LOOM TIE LINE MOUNTING 280 MM
260
CLAMP ,K 147121, Replaced By: N000000000319
260
CLAMP IDLING ADJUSTMENT WIRE CABLE,K 147121
263
SCREW CLAMP TO BRACKET, Replaced By: N007985006581
263
SCREW CLAMP TO BRACKET
266
NUT , Replaced By: N913004006001
266
NUT PUMP TO BRACKET
269
BRACKET HIGH PRESSURE HOSE TO CAB
272
RIVET , NOT USED
999
FITTING , Replaced By: A0019909871
999
HOSE , Replaced By: A3975530082
999
HOSE , Replaced By: A6745530182
999
BRACKET , Replaced By: A3604292940
999
ANGLE , Replaced By: A3604280243
999
HOSE , Replaced By: A3805530082
999
BRACKET , Replaced By: A3604292440
999
GASKET KIT , Replaced By: A0005502583
999
CYLINDER , Replaced By: A0015533505
999
SCREW OIL FILLING TO 000 553 89 01
999
REPAIR KIT , Replaced By: A0005501535
999
CYLINDER , Replaced By: A0015533605
999
PUMP , Replaced By: A0005537901
999
REPAIR KIT , Replaced By: A0005502355
999
REPAIR KIT , Replaced By: A0005530880
999
FITTINGWEBER,TO 001 553 35 05
999
VALVETO 000 553 23 01,000 553 37 01,
999
GUIDE , Replaced By: A0015534905
