Поз.
Артикул
Описание
17
OIL FILTER
32
STUD COVER TO FILTER HOUSING
38
VALVE BY-PASS VALVE
38
VALVE , Replaced By: A6011840132
44
SPRING
50
VALVE SEAT
53
SPRING RETAINER , Replaced By: A6011840131
53
SPRING RETAINER
77
SPRING
80
VALVE
83
VALVE SEAT
86
REGULATOR
86
REGULATOR , Replaced By: A1171800175
89
SPRING
98
COVER
107
GASKET
107
GASKET , THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE, Replaced By: A6161841380
116
SCREW , Replaced By: N304017006020
116
SCREW LICENSE PLATE TO BRACKET
122
SPRING WASHER LICENSE PLATE TO BRACKET
146
SCREW FITTING RETURN
149
SEAL RING VALVE TO VALVE,K 025179
179
COVER , 615.918 000010 615.919 002203
182
SEAL RING , Replaced By: A0159979448
182
SEAL RING
185
NUT COVER TO FILTER HOUSING
215
SEAL RING
215
SEAL RING , Replaced By: A0139978848
218
FILTER ELEMENT UP TO A READING OF 500 KM
227
FILTER ELEMENT , Replaced By: A0001802509
227
FILTER ELEMENT RANGE OF DELIVERY
239
GASKET , Replaced By: A6161840780
239
GASKET OIL FILTER TO CYLINDER CRANKCASE, 615 000178 616 000508 617 000011
248
SCREW CONTROL PLATE TO TRANSMISSION CASE M 8X55
248
SCREWTO 001 466 16 01
251
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
251
SPRING WASHER , Replaced By: N000137008212
266
SENDER UNIT OIL PRESSURE WARNING SWITCH
275
DECALCOMANIA
999
FILTER BOWL , /30 FROM ENGINE: 615.940 10/50,20/60 026061 615.940 12/52,22/62 001122 615.941 10/50,20/60 011372 615.941 12/52,22/62 001498
