Поз.
Артикул
Описание
10
LINE15X1.5, ELIMINATED - NO LONGER REQUIRED
10
TUBE FROM HIGH PRESSURE HOSE TO STEERING, LENGTH AVAILABLE: 3000 MM
15
UNION NUT LINE CONNECTION
15
UNION NUT BUTT SCREW CONNECTION
20
SEAL CONE
20
GLAND LINE CONNECTION
22
FITTING AT BRACKET
22
FITTING FROM 3/2-WAY VALVE TO PRESSURE CONTROL VALVE
22
FITTING QUICK-RELEASE VALVE TO BRACKET
23
HEXAGON NUT. NUT VIBRATION ABSORBER
23
NUT FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
24
LOCK WASHER PROPELLER SHAFT TO REAR AXLES I AND II
25
THRUST RING COMPRESSED AIR LINE TO AIR RESERVOIR AND TO T-FITTING
30
SEAL RING TO 18-MM-DIA. COMPRESSED AIR LINES
32
CONNECTION FITTING ENGINE AIR COMPRESSOR,CONNECTION: "15"
35
FITTING BETWEEN THE LINES
35
FITTING AIR RESERVOIR,CONNECTION: "13"
36
FITTING PLASTIC LINE
36
FITTING PLASTIC LINE
37
WASHER
38
NUT CHECK VALVE TO AIR RESERVOIR
39
T-FITTING LIFTING SYSTEM BRANCH-OFF
39
T-FITTING
40
T-FITTING CHECK VALVE
41
FITTING , Replaced By: A0039979072
43
BRAKE HOSE FROM AIR COMPRESSOR TO PRESSURE REGULATOR
43
BRAKE HOSE FROM AIR COMPRESSOR TO PRESSURE REGULATOR
43
BRAKE HOSE COMPRESSED AIR LINE TO COMPRESSED AIR LINE
45
MUFFLER , FROM IDENT NO.: 052097 WITH MERCEDES-BENZ BODY FROM IDENT NO.: 052032 LESS MERCEDES-BENZ BODY
45
MUFFLER AT AIR COMPRESSOR
50
BRACKET MASTER CYLINDER TO PEDAL BEARING BRACKET
55
SCREW , Replaced By: N304017008021
55
SCREW PIPE CLAMP
60
WASHER , Replaced By: N000125008443
60
WASHER EXHAUST MUFFLER TO STRAP
65
NUT , Replaced By: N913004008001
70
ELBOW FITTING BUTT SCREW CONNECTION "20",5 271048
70
ELBOW FITTING , Replaced By: A0039901671
75
SEAL RING LINE CONNECTION
80
THRUST RING SUCTION LINE TO OIL PUMP
85
NUT , Replaced By: N080705026003
85
NUT 3/2-WAY VALVE TO CAB,4 685151
90
BRACKET AT AIR COMPRESSOR
95
CLAMP SENSOR CABLE TO FRONT AXLE
95
CLAMP LINE MOUNTING
100
SCREW CAB FLOOR COVERING M 6X25
100
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
105
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
107
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
110
NUT PUMP TO BRACKET
110
NUT COVERING TO CAB FIRE WALL
110
NUT , Replaced By: N913004006001
999
T-FITTING AIR DEHYDRATOR,CONNECTION: "2,21"
999
BRACKET COMPRESSED AIR LINE MOUNTING SA 48042
999
CONNECTION FITTING HIGH PRESSURE LINE TO STEERING
