Поз.
Артикул
Описание
6
ACCELERATOR PEDAL , Replaced By: A6243000304
6
ACCELERATOR PEDAL , TO BE ADAPTED DURING ASSEMBLY, Replaced By: A6243000304
7
ACCELERATOR PEDAL (PARTS KIT), RANGE OF DELIVERY INCLUDES: 1X 655 301 00 93, 3X 000965 006077
9
SCREW ACCELERATOR PEDAL
12
BALL PIVOT LOAD SENSOR
12
SCREW CONTROL LEVER TO INJECTION PUMP LEVER
12
BALL PIVOT CONTROL LEVER TO INJECTION PUMP LEVER, Replaced By: N000000004467
15
NUT PUMP TO BRACKET
15
NUT , Replaced By: N913004006001
18
SHIM ACCELERATOR PEDAL
18
SHIM , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 859957, Replaced By: A6153010084
21
BOOT ACCELERATOR PEDAL
21
BOOT ACCELERATOR PEDAL,4 859957
24
SCREW ACCELERATOR PEDAL TO CAB M 6X25
27
SCREW ACCELERATOR PEDAL TO CAB M 6 X 20
30
SERRATED WASHER ACCELERATOR PEDAL TO CAB, ELIMINATED,NO LONGER REQUIRED
33
SCREW VALVE TO BRACKET
33
SCREW VALVE TO BRACKET, Replaced By: N304014008002
36
NUT
39
STOP ACCELERATOR PEDAL
75
ROD LOAD SENSOR CONTROL
75
ROD FROM ACCELERATOR PEDAL TO INTERMEDIATE LEVER, 415 5 014668 416 5 000515 417 4 972023
75
ROD , Replaced By: A3604302992
81
BALL SOCKET PULL ROD TO LEVER
84
NUT BALL PIVOT TO LEVER
87
CIRCLIP. SECURING CLIP BALL SOCKET TO ROD
90
BEARING BRACKET INTERMEDIATE BEARING
90
BEARING BRACKET ,5 181099, Replaced By: A6203000536, +002A6153010088
90
BEARING BRACKET , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 931321, Replaced By: A6203000336
96
LEVER INTERMEDIATE BEARING
96
LEVER , FIRST EXHAUST STOCK OF OLD PARTS FROM IDENT NO. 4 931322-5 068730, Replaced By: A6203000628
96
LEVER , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 931321, Replaced By: A3813000928
102
BALL PIVOT LEVER
102
BALL PIVOT , Replaced By: A3129910120
105
BALL PIVOT BOTTOM B13X5 MM
108
BUSHING INTERMEDIATE LEVER TO BEARING BRACKET,5 943507
108
BUSHING INTERMEDIATE LEVER TO BEARING BRACKET,5 943507
111
COVERING INTERMEDIATE BEARING
111
COVERING , Replaced By: A6153010088
114
LOCK PLATE INTERMEDIATE BEARING
117
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
117
SCREW END PIECE TO EXHAUST PIPE M 10X25
120
NUT STRAP TO BRACKET
120
NUT , Replaced By: N910113010000
121
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
123
PULL ROD FROM ACCELERATOR PEDAL TO INTERMEDIATE LEVER
129
BALL SOCKET ROD TO BALL PIVOT
132
BALL SOCKET ROD TO BALL PIVOT
135
NUT
138
SECURING CLIP. CIRCLIP
141
MANUAL CONTROL IDLING ADJUSTMENT
142
GUIDE MANUAL CONTROL
144
KNOB MANUAL CONTROL
144
KNOB , Replaced By: A6153020001
147
FITTED WASHER MANUAL CONTROL
147
LOCK , Replaced By: N000988030003
150
NUT MANUAL CONTROL
153
WIRE CABLE IDLING ADJUSTMENT, 415 5 014668 416 5 000515 417 4 972023
153
WIRE CABLE IDLING ADJUSTMENT
153
WIRE CABLE , Replaced By: A6203000130
153
WIRE CABLE , Replaced By: A6203000130
153
WIRE CABLE IDLING ADJUSTMENT, 415 5 014668 416 5 000515 417 4 972023
156
BRACKET
156
BRACKET , Replaced By: A3813020240
157
CLAMPING PIECE FLEXIBLE SHAFT TO CAB FIRE WALL
157
CLAMPING PIECE WIRE CABLE TO FIRE WALL
162
COMBINATION BOLT BRACKET TO WINDOW SILL GIRDER
162
SHEET METAL SCREW , Replaced By: N914031005208
164
GROMMET WIRE CABLE THRU WINDOW SILL
164
GROMMET
166
BRACKET WIRE CABLE TO FIRE WALL, 415 5 014668 416 5 000515 417 4 972023
167
BRACKET WIRE CABLE TO RADIATOR MOUNTING CONSOLE
180
BRACKET WIRE CABLE TO FRAME SIDE MEMBER, 415 5 014668 416 5 000515 417 4 972023
183
BRACKET CABLE HARNESS MOUNTING
186
CLAMP DELIVERY AND SUCTION LINES TO STEERING
186
CLAMP , Replaced By: A6739950001
187
CLAMPING PIECE CABLE TO BRACKET
188
COVER CABLE TO BRACKET
190
SCREW LONGITUDINAL DIFFERENTIAL LOCK VALVE TO BRACKET,5 963747
190
SCREW CAB FLOOR COVERING M 6X25
191
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
999
CLAMPING PIECE FLEXIBLE SHAFT TO FRAME SIDE MEMBER
999
CLAMPING PIECE CABLE TO BRACKET
999
PAD ACCELERATOR PEDAL
999
CLAMPING PIECE CABLE PULL TO FIRE WALL
999
GUIDE RAIL ACCELERATOR PEDAL TO FLOOR PLATE
999
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
999
WASHER COMPRESSED AIR LINE TO BRACKET
999
SCREW COVER PLATE TO BRACKET
999
SCREW GUIDE RAIL RETROFIT M 6X35, BORE THREADED HOLES IN CAB FLOOR TO 6.5MM
