Поз.
Артикул
Описание
6
LINE AIR COMPRESSOR,PRESSURE REGULATOR, DEHYDRATOR 15X1.5 MM, LENGTH AVAILABLE: 3000 MM
6
LINE AIR COMPRESSOR,PRESSURE REGULATOR, DEHYDRATOR 15X1.5 MM, LENGTH AVAILABLE: 3000 MM
6
LINE AIR COMPRESSOR,PRESSURE REGULATOR, DEHYDRATOR 15X1.5 MM, LENGTH AVAILABLE: 3000 MM
9
UNION NUT LINE CONNECTION
9
UNION NUT BUTT SCREW CONNECTION
12
GLAND LINE CONNECTION
15
THRUST RING BUTT SCREW CONNECTION
18
SEAL RING DOUBLE BRAKE LINE COUPLING, CONNECTIONS: "11,12"
18
SEAL RING , Replaced By: N007603012121
21
DOUBLE FITTING BETWEEN THE LINES, BUTT CONNECTION
25
BULKHEAD FITTING THROUGH SIDE MEMBER, BUTT CONNECTION
28
NUT CHECK VALVE TO AIR RESERVOIR
44
CLAMP DELIVERY AND SUCTION LINES TO STEERING
44
CLAMP , Replaced By: A6739950001
46
SCREW CLAMP MOUNTING M 6X16
46
SCREW , Replaced By: N000000001146
46
SCREW DELIVERY AND SUCTION LINES TO ENGINE, TOP
48
WASHER COMPRESSED AIR LINE TO BRACKET
48
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
49
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
50
NUT PUMP TO BRACKET
50
NUT , Replaced By: N913004006001
243
PRESSURE REGULATOR , Replaced By: A0024314906
244
PRESSURE REGULATORWABCO, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
244
PRESSURE REGULATOR , Replaced By: A0024314906
245
PRESSURE REGULATOR , Replaced By: A0024314306
245
PRESSURE REGULATOR , Replaced By: A0024313406
248
PRESSURE REGULATORKNORR 90310
248
PRESSURE REGULATORBOSCH
255
SCREW REAR AXLE REGULATING SOLENOID VALVE
257
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
257
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
257
NUT , Replaced By: N913004008001
259
HOSE PRESSURE REGULATOR,CONNECTION: "30", ORDER BY THE METER
259
INSULATING HOSE PRESSURE REGULATOR,CONNECTION "3", ORDER BY THE METER5 148812
261
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
261
CLAMP , Replaced By: N000000000667
261
HOSE CLAMP LINE MOUNTING
261
CLAMP , Replaced By: A0059970190
263
LOOM TIE LINE MOUNTING 280 MM
266
DOUBLE FITTING BETWEEN THE LINES, BUTT CONNECTION
268
O-RING CHECK VALVE TO AIR RESERVOIR
270
THRUST RING CHECK VALVE TO AIR RESERVOIR
270
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
271
NUT CHECK VALVE TO AIR RESERVOIR
999
VALVETO 003 429 04 44,WABCO
999
VALVE GASKET KIT TO 003 429 16 44,BOSCH,UP TO 03.82
999
VALVEBOSCH
999
BLEEDER VALVE , Replaced By: A0004310265
999
BLEEDER VALVE , Replaced By: A0004310265
999
REPAIR KITTO 000 429 27 95,WABCO
999
FITTINGWABCO
999
GUIDE , Replaced By: N071752014000
999
CUPTO 007 420 68 18,WABCO
999
SEAL RINGKNORR
999
PROTECTIVE CAPTO 008 420 62 18,KNORR
999
VALVE TAPPETTO 002 429 96 44,VOSS
999
FILTER ELEMENTTO 000 429 28 95,GRAU
999
FILTER ELEMENT MINOR TO 000 429 27 95,WABCO
999
DIAPHRAGM , Replaced By: A0004290745
999
THRUST WASHERTO 003 429 12 44,SCHAEFER
999
SEAL CONETO 003 429 12 44,SCHAEFER
999
DIAPHRAGM
999
FILTER ELEMENTTO 000 429 25 95,BOSCH
999
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
999
SEAL RINGTO 002 429 96 44,VOSS
999
AIR CLEANERBOSCH
999
AIR CLEANERKNORR
999
AIR CLEANERWABCO
999
AIR CLEANERGRAU
999
ADAPTER FITTING LINE CONNECTION TO ENGINE
999
REPAIR KIT , Replaced By: A0014308460, +001A0004303506
999
REPAIR KITTO 000 429 26 95,KNORR
999
REPAIR KITTO 002 431 83 06, KNORR 90309
999
REPAIR KITTO 002 431 84 06, KNORR 90310
999
REPAIR KIT BLEEDER VALVE TO 001 431 67 05,BOSCH
999
REPAIR KIT DIAPHRAGM PART BOSCH,209
999
REPAIR KIT , Replaced By: A0024209824, +002A0024209424
999
REPAIR KIT PRESSURE LIMIT VALVE
999
REPAIR KIT FOUR-CIRCUIT PROTECTIVE VALVE WABCO
999
VALVE , Replaced By: A3075530107
999
DIAPHRAGMTO 001 431 90 06,GRAU,5 148812
999
VALVE DISCTO 001 431 90 06,GRAU,5 148812
999
VALVE DISCTO 001 431 90 06,GRAU,5 148812
999
VALVE SEATGRAU
999
VALVE SEATTO 001 431 90 06,GRAU,5 148812
999
DIAPHRAGMTO 007 420 42 18,KNORR
999
DIAPHRAGMBOSCH,K 262627
999
VALVE
999
VALVETO 001 431 90 06,GRAU,5 148812
999
STRAINERTO 001 431 90 06,GRAU,5 148812
999
VALVEWABCO
999
REPAIR KIT OVERFLOW VALVE TO 003 429 09 44,WABCO
999
SEALING CORDTO 000 429 27 95, WABCO
999
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
999
ELBOW FITTING ANTI-FREEZE DEVICE,CONNECTION: "10", BUTT CONNECTION
999
CONNECTOR REPAIR SIZE
999
SPRING , Replaced By: A0009935205
999
SPRINGBOSCH,5 7999995 800000 - 5 8127305 900000 - 5 936365
999
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
999
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION
999
LOCK ELECTRIC CABLE THRU CAB FLOOR
999
SCREW. UNION SCREW LINE CONNECTION
999
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
999
HANDLEKNORR
999
VALVE (RELAY VALVE) GRAU
999
REPAIR KIT PRESSURE REGULATOR WABCO
999
VALVE (REGULATING VALVE),5 023386 TO BE ADAPTED DURING ASSEMBLY
999
GASKET KITBOSCH
999
REPAIR KIT TRISTOP CYLINDER TO 008 420 90 18, BOSCH
999
PROTECTIVE CAPTO WABCO
999
CUPTO 002 431 04 06,BOSCH
999
PROTECTIVE CAPTO BOSCH
999
PROTECTIVE CAPKNORR
999
SEAL RING28X2 MM,GRAU
999
SEAL RING86X2 MM,GRAU
999
PRESSURE REGULATOR ,5 148812, Replaced By: A0024314306
999
VALVE , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. K 087820 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART, Replaced By: A0034315006
999
REPAIR KITBOSCH
999
T-FITTING RIGHT SPRING LOAD ACCUMULATOR BRAKE CYLINDER,CONNECTION "1"
999
T-FITTING LEFT AND RIGHT BRAKE HOSES
999
T-FITTING PRESSURE RELIEF VALVE,CONNECTION: "10"
999
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION
999
ELBOW FITTING AIR RESERVOIR,CONNECTION: "13", PLUG CONNECTION
999
FITTING SHUTTLE VALVE,CONNECTION: "20"
999
SEAL RINGTO 000 429 25 95,BOSCH
999
REPAIR KIT SPRING LOAD ACCUMULATOR PART KNORR,K 262627
999
REPAIR KIT. BRAKE CYLINDER DIAPHRAGM PART TO 007 420 42 18, KNORR
999
REPAIR KIT DIAPHRAGM PART KNORR, Replaced By: A0024209524
999
VALVE , Replaced By: A0044293144
999
VALVE ,K 025179, Replaced By: A0044297244
999
VALVE (CHECK VALVE) VOSS
999
REPAIR KIT VALVE KIT WABCO,5 148812
999
VALVE (PRESSURE LIMIT VALVE)
999
VALVE , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. K 087820, Replaced By: A0034315006
999
PRESSURE REGULATOR WITH TIRE INFLATING CONNECTION BOSCH,5 7999995 800000 - 5 8127305 900000 - 5 936365 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
PRESSURE REGULATORKNORR,5 7999995 800000 - 5 8127305 900000 - 5 936365
999
VALVE , Replaced By: A0034315006
999
REPAIR KIT SLAVE CYLINDER TO 006 420 15 18, UP TO SCHAEFER CHARACTERISTIC NO.489
999
REPAIR KIT , Replaced By: A0025865242
999
REPAIR KIT , Replaced By: A0004201071
999
REPAIR KIT , Replaced By: A0004301109
999
REPAIR KITGRAU,5 148812
999
REPAIR KITTO BOSCH
999
REPAIR KITTO 001 431 12 06, KNORR 3200
999
ELBOW FITTING ,5 181111 10/50 616.121,122,131,1325 208196 20/60 616.121,122,131,1325 297633 616.024,026,027,028,065
999
T-FITTING PRESSURE RELIEF VALVE,CONNECTION: "10"
999
FITTING AIR DEHYDRATOR,CONNECTION: "10",5 433280
999
VALVE (CHECK VALVE) WABCO
999
VALVE (RELAY VALVE) BOSCH
999
REPAIR KIT FOUR-CIRCUIT PROTECTIVE VALVE GRAU,5 7999995 800000 - 5 8127305 900000 - 5 936365
999
GASKET KIT FOUR-CIRCUIT PROTECTIVE VALVE GRAU,000 2
999
VALVE (FOUR-CIRCUIT PROTECTIVE VALVE) WABCO
999
REPAIR KITTO 001 431 87 06,KNORR
999
REPAIR KIT , EXHAUST STOCK OF OLD PARTS NUMBER FIRST UP TO WABCO NR.0182, Replaced By: A0004306360
999
FITTING CONDENSATION TANK,CONNECTION: "20", 621.416 UP TO IDENT NO. 5 009666 621.511 UP TO IDENT NO. 5 040486 621.512 UP TO IDENT NO. 5 024291
999
VALVE (OVERFLOW VALVE) WABCO
999
VALVE PRESSURE LIMIT M 22,K 025180
999
SEAL RINGBOSCH
999
SEAL RINGTO 000 429 27 95, NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IN REPAIR KIT
999
SEAL RINGTO 001 431 43 05,002 431 05 05
999
SPRINGTO 000 429 27 95,WABCO
999
SEAL RING22.3X2.4 MM,GRAU
999
SEAL RINGTO 000 429 28 95,GRAU
999
SEAL RINGTO 001 431 90 06,GRAU,5 148812
999
SEAL RINGTO 001 431 90 06,GRAU,5 148812
999
SEAL RINGTO 001 431 90 06,GRAU,5 148812
999
SEAL RINGTO 001 431 43 05,002 431 05 05
999
FITTING SHUTTLE VALVE,CONNECTION: "20",5 434013
999
SEAL RING34.6X2.6 MM
999
SEAL RING19.3X2.4 MM,TO 003 429 04 44,WABCO
999
SEAL RINGTO 000 429 28 95,GRAU
999
SEAL RING56X1.7 MM
999
SEAL RING13.6X2 MM,TO 003 429 12 44,SCHAEFER
999
SEAL RING15.3X2.4 MM,TO 003 429 12 44,SCHAEFER
999
SEAL RINGTO 001 431 43 05
999
SEAL RING , Replaced By: A0049970248
999
SEAL RINGTO 000 429 25 95,BOSCH
999
SEAL RINGTO 000 429 27 95, WABCO
999
PROTECTIVE CAP , Replaced By: A0004210887
999
WASHER BRACKET TO CROSS MEMBER,5 434013
999
ADHESIVE FOIL GUIDE SIGN
999
BEARING BRACKET TRISTOP CYLINDER
999
BRACKET COMPRESSED AIR LINE TO ENGINE BEARING BRACKET
999
BRACKET COMPRESSED AIR LINE TO BUMPER STRUT
999
BRACKET RIGHT COMPRESSED AIR LINES
999
BRACKET , Replaced By: A6154200186
999
LOCK BRAKE HOSE TO ANGLE
999
BRACKET FOR PASSAGE OF LINE
999
BRACKET FOR PASSAGE OF LINE
999
BRACKET , NOT USED
999
COVERING CHECK VALVE,5 298639
999
BRACKET PRESSURE RATIO VALVE,5 180559
999
BRACKET PRESSURE RATIO VALVE,5 180559
999
FITTING ENGINE AIR COMPRESSOR,CONNECTION: "20"
999
REPAIR KIT. TS SEALING RING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 22
999
NUT COMPRESSED AIR LINE THRU FRAME,5 395034
999
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "22"
999
SCREW , Replaced By: N304017008039
999
SCREW , Replaced By: N304017008034
