Поз.
Артикул
Описание
4
CLUTCH PRESSURE PLATE CLUTCH, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
4
CLUTCH PRESSURE PLATE , PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
8
HOUSING
12
SPRING SUSPENDED BELOW LEAF SPRING
12
SPRING SUSPENDED IN CLUTCH PRESSURE PLATE HOUSING
14
SPRING SUSPENDED BELOW LEAF SPRING
14
SPRING SUSPENDED IN CLUTCH PRESSURE PLATE HOUSING
16
PRESSURE PLATE CLUTCH PRESSURE PLATE
16
PRESSURE PLATE
20
RELEASE LEVER CLUTCH ACTUATION
26
SPINDLE RELEASE LEVER,CLUTCH PRESSURE PLATE
26
SPINDLE FOR BEDDING THE LEVERS IN CLUTCH PRESSURE PLATE
30
SPINDLE FOR BEDDING THE LEVERS IN BRACKETS
34
ROLLER FOR BEDDING THE LEVERS IN BRACKETS
38
BRACKET RELEASE LEVER
42
LOCK PLATE RELEASE LEVER TO SHAFT
50
SLEEVE CLUTCH PRESSURE PLATE
54
FLANGE CLUTCH PRESSURE PLATE
54
FLANGE , Replaced By: A0002521245
54
FLANGE
62
PRESSURE SPRING SPRING STEEL WIRE DIA., 3.75 MM
62
PRESSURE SPRING SPRING STEEL WIRE DIA., 3.75 MM
64
PRESSURE SPRING SPRING STEEL WIRE DIA., 3.5 MM
64
PRESSURE SPRING SPRING STEEL WIRE DIA., 4.00 MM
68
LEAF SPRING THIGH SPRING SUSPENDED BELOW LEAF SPRING
68
LEAF SPRING THIGH SPRING SUSPENDED IN CLUTCH PRESSURE PLATE HOUSING
72
NUT FOR BRACKETS
76
LOCK FOR BRACKETS
78
SCREW RELEASE LEVER,BRACKET
80
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
84
SCREW CLUTCH TO FLYWHEEL
84
SCREW , Replaced By: N304017010055
84
SCREW , Replaced By: N304017010050
88
CLUTCH DISC ,5 234954
88
CLUTCH DISC ASBESTOS-FREE LINING
88
CLUTCH DISC ASBESTOS-FREE LINING, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
88
CLUTCH DISC
88
CLUTCH DISC , THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE, Replaced By: A0062504603
88
CLUTCH DISC
88
CLUTCH DISC , THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE, Replaced By: A0072500803
88
CLUTCH DISC , THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE, Replaced By: A0062504503
88
CLUTCH DISC ASBESTOS-FREE LINING, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
88
CLUTCH DISC ASBESTOS-FREE LINING
100
LEAF SPRING
100
LEAF SPRING
100
LEAF SPRING , REBORE HOLE IN SUPPORTING PLATE FROM 5.2MM TO 6.2MM, Replaced By: A0002523819, +002A0002523975
104
RIVET LINING WITH CLUTCH DISC
104
RIVET LEAF SPRING TO CLUTCH DISC
104
RIVET LEAF SPRING TO CLUTCH DISC 5X6 MM
104
RIVET , Replaced By: A0002522075
108
CLUTCH LINING
108
CLUTCH LINING ASBESTOS-FREE
108
CLUTCH LINING
108
CLUTCH LINING ASBESTOS-FREE
115
RIVET LINING WITH INTERMEDIATE SPRING,5 563495
115
RIVET LINING WITH INTERMEDIATE SPRING
115
RIVET LINING WITH CLUTCH DISC,5 563495
115
RIVET LEAF SPRING TO CLUTCH DISC
999
LOCK
999
LEVER CLUTCH ACTUATION,4 601610
