Поз.
Артикул
Описание
268
LINE , Replaced By: A0004291601
268
LINE (SUCTION LINE),FROM HOSE TO OIL PUMP
268
LINE (SUCTION LINE),FROM HOSE TO OIL PUMP
268
LINE , Replaced By: A0004291601
275
GLAND , Replaced By: A0019901267
275
SEAL CONE LINE CONNECTION
282
UNION NUT LINE CONNECTION, Replaced By: N000000006243
282
NUT LINE CONNECTION
380
LINE DELIVERY LINE
380
LINE DELIVERY LINE
436
LINE FROM STEERING TO PRESSURE LIMIT VALVE T-FITTING,CIRCUIT II
436
LINE DELIVERY LINE
443
LINE RETURN LINE
443
LINE RETURN LINE
450
LINE RETURN LINE
457
LINE FROM RETURN LINE TO OIL TANK
492
HOSE , Replaced By: A3859971682
492
HOSE , NOT USED
499
HOSE FROM RETURN LINE TO OIL TANK
513
LINE 2/2-WAY VALVE
520
UNION NUT LINE CONNECTION, Replaced By: N000000006239
520
UNION NUT LINE CONNECTION
527
SEAL CONE LINE CONNECTION
534
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
534
CLAMP DELIVERY AND SUCTION LINES TO STEERING
534
CLAMP HOSE TO BRACKET 25/20,5 206397
541
SCREW DELIVERY AND SUCTION LINES TO ENGINE, TOP
548
VALVE FLOW INDICATOR,PRESSURE LIMIT VALVE, CIRCUITS I AND II
548
VALVE , Replaced By: A0004602084
555
BALL
562
SPRING
569
PISTON
576
BUSHING
583
SENDER UNIT
590
SENDER UNIT STEERING FAILURE
590
INDICATOR , Replaced By: A0105429317
597
SEAL CONE LINE CONNECTION
597
GLAND , Replaced By: A0019901267
604
UNION NUT LINE CONNECTION, Replaced By: N000000006243
604
NUT LINE CONNECTION
611
FITTING STEERING GEAR DELIVERY LINE,CIRCUIT II
618
FITTING OIL LINE CONNECTION
625
FITTING FLOW INDICATOR,PRESSURE LIMIT VALVE, CIRCUITS I AND II
632
VALVE (PRESSURE LIMIT VALVE) 100 BAR
632
VALVE , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0004664291
632
VALVE , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0004664291
632
VALVE PRESSURE LIMIT,CIRCUIT II 150 BAR
632
VALVE PRESSURE LIMIT,CIRCUIT II 150 BAR
639
PISTON , Replaced By: A0004665783
639
PISTON
639
PISTONTO 000 466 34 91
639
PISTONTO 000 466 33 91
646
SPRING , Replaced By: A0029935201
646
SPRING
646
SPRING
653
SEAL RING
653
SEAL RING
660
SCREW PLUG
660
SCREW PLUG
667
FITTING
667
FITTING
674
SEAL RING AIR COMPRESSOR,CONNECTION: "10"
674
SEAL RING AIR COMPRESSOR,CONNECTION: "10"
681
LINE (SUCTION LINE),FROM HOSE TO OIL PUMP
681
LINE , Replaced By: A0004291601
688
SCREW-IN FITTING RETURN, FROM STEERING TO OIL TANK
688
SCREW-IN FITTING RETURN, FROM STEERING TO OIL TANK
695
SEAL RING SOLENOID VALVE A 18X24
695
SEAL RING SOLENOID VALVE A 18X24
702
FITTING OIL LINE CONNECTION
709
FITTING PRESSURE LIMIT,CIRCUIT II
716
FITTING (DELIVERY LINE),FROM PUMP TO STEERING, Replaced By: A9329970772
716
FITTING (DELIVERY LINE),FROM PUMP TO STEERING
723
T-FITTING POWER STEERING
730
COUPLING BEARING BRACKET TO AIR COMPRESSOR HOUSING
737
SEAL CONE LINE CONNECTION
737
GLAND , Replaced By: A0019901967
744
UNION NUT LINE CONNECTION
744
UNION NUT LINE CONNECTION, Replaced By: N000000006239
751
VALVE , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0004664291
751
VALVE PRESSURE LIMIT,CIRCUIT II 150 BAR
758
SCREW-IN FITTING DELIVERY LINE TO PUMP
765
SEAL RINGTO 000 270 08 89,16 89,25 89
772
T-FITTING SUPPLY LINE FOR TRANSMISSION
779
BRACKET DELIVERY LINE TO BRACKET
786
BRACKET AT TRANSMISSION
793
BRACKET AT TRANSMISSION
800
BRACKET , Replaced By: A6205243040
800
BRACKET 2/2-WAY VALVE AND PRESSURE LIMIT VALVE
803
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
806
SCREW , Replaced By: N304017010055
806
SCREW , Replaced By: N304017010050
809
NUT , Replaced By: N910113010000
809
NUT STRAP TO BRACKET
812
SCREW 3/2-WAY VALVE TO BRACKET, UP TO IDENT NO. 5 385481 FROM IDENT NO. SEE STANDARD VERSION
815
NUT TWO-WAY VALVE TO BRACKET
818
BRACKET FRONT AXLE STABILIZER
821
SCREW TRAILER COUPLING TO REAR CROSS MEMBER
824
BRACKET AT FRAME
827
BRACKET AT FRAME
830
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
830
SCREW , Replaced By: N304017008027
833
NUT , Replaced By: N913004008001
837
SCREW DE-AERATION LINE TO THERMOSTAT BRACKET M 10X120
840
NUT , Replaced By: N910113010000
840
NUT STRAP TO BRACKET
925
FITTING POWER STEERING PUMP
925
FITTING AIR DEHYDRATOR,CONNECTION: "10",5 433280
925
FITTING SUCTION LINE TO OIL PUMP
925
FITTING SUCTION LINE TO OIL PUMP
925
FITTING , Replaced By: A0039971372
928
SEAL RING POWER STEERING PUMP TO BEARING FLANGE
928
SEAL RING LINE CONNECTION
931
FITTING , Replaced By: A0809972472, +001A6999970189
931
FITTING BEARING BRACKET TO AIR COMPRESSOR HOUSING
934
FITTING STEERING GEAR DELIVERY LINE,CIRCUIT II
934
FITTING PRESSURE LIMIT,CIRCUIT II
937
FITTING POWER STEERING
937
FITTING DELIVERY LINE TO PUMP
937
SCREW-IN FITTING RETURN, FROM STEERING TO OIL TANK
940
T-FITTING POWER STEERING
940
FITTING , Replaced By: A0019900970
943
FITTING (DELIVERY LINE),FROM PUMP TO STEERING
943
FITTING (DELIVERY LINE),FROM PUMP TO STEERING
943
FITTING (DELIVERY LINE),FROM PUMP TO STEERING, Replaced By: A9329970772
946
COUPLING BEARING BRACKET TO AIR COMPRESSOR HOUSING
949
SEAL RINGTO 006 997 00 72
949
SEAL RING SOLENOID VALVE A 18X24
952
UNION NUT LINE CONNECTION, Replaced By: N000000006239
952
UNION NUT LINE CONNECTION
955
GLAND , Replaced By: A0019901967
955
SEAL CONE LINE CONNECTION
999
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
999
FITTING POWER STEERING PUMP TO BEARING FLANGE
999
HOSE , Replaced By: A3849977482
999
FITTING , Replaced By: A0049972272
999
BRACKET
999
LINE (RETURN LINE),FROM STEERING TO OIL TANK
999
BRACKET
999
BRACKET
999
BRACKET , Replaced By: A6454310740
999
LINE (RETURN LINE),FROM STEERING TO OIL TANK, NOT USED
999
LINE FROM STEERING TO HOSE
999
LINE (RETURN LINE),FROM STEERING TO OIL TANK,5 424435
999
LINE (RETURN LINE),FROM STEERING TO OIL TANK,5 424435
999
LINE , Replaced By: A0004291601
999
LINE FROM POWER STEERING PUMP AT TRANSMISSION TO CUT-IN VALVE
999
LINE FROM HIGH PRESSURE HOSE TO CYLINDER
999
LINE FROM HIGH PRESSURE HOSE TO STEERING
999
LINE FROM HIGH PRESSURE HOSE TO CYLINDER
999
LINE FROM STEERING TO HOSE
999
LINE FROM POWER STEERING PUMP AT TRANSMISSION TO CUT-IN VALVE,5 398761
999
LINE FROM POWER STEERING PUMP AT TRANSMISSION TO CUT-IN VALVE,5 393651
999
LINE (DELIVERY LINE) FROM CUT-IN VALVE TO STEERING,5 398761
999
LINE
999
LINE FROM HIGH PRESSURE HOSE TO STEERING,5 429729
999
LINE FROM HIGH PRESSURE HOSE TO STEERING,5 429729
999
LINE FROM POWER STEERING PUMP AT TRANSMISSION TO CUT-IN VALVE,5 4297295 901270
999
LINE FROM POWER STEERING PUMP AT ENGINE TO CUT-IN VALVE,5 429729
999
LINE FROM HIGH PRESSURE HOSE TO CYLINDER
999
LINE FROM HIGH PRESSURE HOSE TO STEERING
999
LINE , Replaced By: A0005516156
999
FITTING AIR COMPRESSOR,CONNECTION: "10"
999
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
999
CLAMP FEED LINE TO THERMOSTAT
999
BRACKET , Replaced By: A3812950440
999
HOSE FROM POWER STEERING PUMP AT ENGINE TO CUT-IN VALVE,5 429729
999
SEAL RING PISTON ROD GUIDE
999
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
999
LOCK PISTON ROD GUIDE
999
LOCK PISTON ROD GUIDE
999
NUT CYLINDER
999
TUBE FROM HIGH PRESSURE HOSE TO STEERING
999
PISTON
999
SEAL RING PISTON ROD GUIDE
999
WASHER
999
SPACER WASHER
999
VALVE (CUT-IN VALVE),AT FRAME SIDE MEMBER IN FRONT OF STEERING BOX, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
SPACER RING
999
BOOT
999
WASHER
