Поз.
Артикул
Описание
150
SUPPORT EXHAUST MUFFLER
150
SUPPORT EXHAUST MUFFLER
150
SUPPORT , Replaced By: A6254900634
155
SCREW BRACKET TO SIDE MEMBER M 14X1.5X35
155
SCREW BRACKET TO CAB CONSOLE M14X1.5X40
155
SCREW , Replaced By: N308676014020
160
NUT , Replaced By: N910113014001
160
NUT BRACKET TO SIDE MEMBER
165
NUT SUPPORT TO SIDE MEMBER
170
COVERING SCREENING PLATE TO MUFFLER
175
SCREW , Replaced By: N304017008016
175
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
180
WASHER , Replaced By: N000125008443
180
WASHER EXHAUST MUFFLER TO STRAP
185
FRONT EXHAUST PIPE
190
FRONT EXHAUST PIPE
190
FRONT EXHAUST PIPE
195
END PIECE
197
CONNECTOR FROM EXHAUST MUFFLER TO DUMPER TROUGH, LEFT
200
CLAMP EXHAUST PIPE TO BRACKET
205
SCREW , Replaced By: N304017010002
205
SCREW BRACKET TO SIDE MEMBER
210
NUT STRAP TO BRACKET
210
NUT , Replaced By: N910113010000
215
CLAMP EXHAUST PIPE
215
CLAMP , Replaced By: A6554920340
220
SCREW , Replaced By: N304017010002
220
SCREW BRACKET TO SIDE MEMBER
225
NUT STRAP TO BRACKET
225
NUT , Replaced By: N910113010000
230
BRACKET EXHAUST PIPE TO SUPPORT
230
BRACKET EXHAUST PIPE ON BATTERY EQUIPMENT CARRIER
235
BRACKET INTERMEDIATE PIECE TO FRAME
240
SCREW END PIECE TO EXHAUST PIPE M 10X25
240
SCREW END PIECE TO EXHAUST PIPE M 10X25
245
NUT STRAP TO BRACKET
245
NUT STRAP TO BRACKET
245
NUT , Replaced By: N910113010000
250
CLAMP EXHAUST PIPE TO BRACKET
250
CLAMP , Replaced By: N071555120502
250
CLAMP EXHAUST PIPE
250
CLAMP EXHAUST PIPE TO BRACKET
250
CLAMP EXHAUST PIPE TO BRACKET
250
CLAMP EXHAUST PIPE TO BRACKET
265
SCREW EXHAUST PIPE TO BRACKET
265
SCREW EXHAUST PIPE TO SIDE MEMBER
265
SCREW EXHAUST PIPE TO SIDE MEMBER
265
SCREW BRACKET TO SIDE MEMBER
265
SCREW , Replaced By: N304017010002
265
SCREW SUPPORT TO SIDE MEMBER M14X40
265
SCREW REAR EXHAUST PIPE TO MUFFLER
270
WASHER STRUT TO CROSS MEMBER
270
WASHER , Replaced By: N007349010007
275
NUT PARTICLE FILTER M14
275
NUT STRAP TO BRACKET
275
NUT STRAP TO BRACKET
275
NUT , Replaced By: N910113010000
275
NUT EXHAUST PIPE TO SIDE MEMBER
275
NUT EXHAUST PIPE TO SIDE MEMBER
275
NUT EXHAUST PIPE TO SIDE MEMBER
282
PROTECTIVE PLATE (HEAT SHIELD)
292
SCREW , Replaced By: N304017006020
292
SCREW LICENSE PLATE TO BRACKET
297
NUT PUMP TO BRACKET
297
NUT , Replaced By: N913004006001
999
SCREW BRACKET TO BEARING BRACKET,K 274033
999
SCREW BRACKET TO SIDE MEMBER M 14X55,5 543914
999
SCREW BRACKET TO SIDE MEMBER,5 597425
999
WASHER CROSS MEMBER TO SUPPORT
999
RAIL FENDER TO BODY
999
SPLASH GUARD FENDER
999
REINFORCEMENT FENDER
999
BRACKET FENDER
999
BRACKET INTERMEDIATE PIECE TO EXHAUST MUFFLER
999
BRACKET INTERMEDIATE PIECE TO FRAME
999
BRACKET BRACKET TO CROSS MEMBER
999
CONNECTOR FROM EXHAUST MUFFLER TO DUMPER TROUGH, LEFT
999
CONNECTOR FROM EXHAUST MUFFLER TO DUMPER TROUGH, LEFT
999
FENDER , Replaced By: A6525220701, +004A6205205241, +004A3935220029, +032N000603006062, +032N009021006208, +032N304032006004
999
FENDER , TO BE ADAPTED DURING ASSEMBLY
999
COVERING EXHAUST MUFFLER, NOT USED
999
SCREW REINFORCEMENT WITH FENDER BRACKET TO FENDER
999
WASHER COMPRESSED AIR LINE TO BRACKET
999
NUT SPRING-LOADED PUSH ROD
