Mercedes N000000001476 - АВТОЗАПЧАСТЬ

CITARO 12M 2-TUERER 628.037

42 BRAKES - 150 MOUNTING OF LINES,HOSES,TEST CONNECTIONS IL. 1

Поз.
Артикул
Описание
175
A6286903722
175
A6286903522
176
A6286910251
179
A0009884264
SASH FASTENER
181
A0006890801
191
A0009872523
PLASTIC SECTION SELF-ADHESIVE ON ONE SIDE 2,0X10 MM, ORDER BY THE METER
191
A0019899785
ADHESIVE TAPE COVER TO AIR DUCT 1200 MM, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
201
A3236800055
204
A6286800283
226
A6286902722
226
A6286908422
228
A6286902922
232
A6286908522
232
A6286902822
234
A6286903022
240
A0006910051
240
A0006910151
242
A3236958214
244
A3236958314
246
A3236959114
246
A6446952314
248
A6446952214
248
A3236959214
250
A3046950714
252
A3046950814
795
N000000000527
TAPPING SCREW STEERING COLUMN MOUNTED SWITCH PLUGCONNECTION
796
N000000001526
HEXALOBULAR BOLTM5X12
797
N000000003260
WASHER LINE MOUNTING
799
N000000001476
HEXALOBULAR BOLT BASIC MODULE AT SUPPORT M6X16,01.08.08
812
A0049941645
LOCK NUT. SPRING NUT MOUNTING PARTS
942
A6286820023
INSULATION
952
N913023006002
NUT BRACKET TO FIRE WALL
952
N910112006001
NUT , Replaced By: N913023006001
960
N910105006010
SCREWM6X60
969
A0049941745
LOCK NUT. SPRING NUT STEP TO ENTRANCE
970
A0049941245
NUT LOCK TO COVER
993
A0019894598
SEALING STRIP30X30MM, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
