Поз.
Артикул
Описание
45
SCREW , Replaced By: N910143008000
165
ANGLE
175
FLAP COWL, NO.7E23I.......I.......I I II
176
HINGE
177
TOTAL FOAMED MATERIAL USE10X0,8MM, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
179
LATCH
181
LOCK
183
ANGLE FRONT
187
NUT RETAINER REAR SEAT BENCH BACKREST TO REAR PANEL
190
COVER VEHICLE WIDTH 2550MM
190
COVER COWL
190
COVER COWL
190
COVER COWL
192
COVER COWL,LEFT
192
PANELLING VEHICLE WIDTH 2550MM, NO.7E23I.......I.......I I II
195
COVER COWL
199
COVER COWL
201
BEAM FRONT CENTRAL
203
PANELLING FRONT LEFT
205
PANELLING FRONT RIGHT, NO.7C01I.......I.......I I II
208
PANELLING ROOF, FRONT LEFT, NO.7E23I.......I.......I I II
208
PANELLING FRONT RIGHT, NO.7E23I.......I.......I I II
208
PANELLING ,NR.7E85 I ....... I ....... I ....... I ....... II
212
FLAP
215
HINGE
218
LOCK
221
COVERING INTERIOR INDICATION
221
COVERING INTERIOR INDICATION
221
COVERING INTERIOR INDICATION
221
COVERING INTERIOR INDICATION
221
COVERING INTERIOR INDICATION
221
COVERING INTERIOR INDICATION FA. LAWO
221
COVERING INTERIOR INDICATION FA. LAWO
221
COVERING INTERIOR INDICATION
221
COVERING INTERIOR INDICATION
221
COVERING INTERIOR INDICATION
221
COVERING INTERIOR INDICATION
221
COVERING INTERIOR INDICATION
221
COVERING INTERIOR INDICATION
221
COVERING INTERIOR INDICATION
221
COVERING INTERIOR INDICATION
221
COVERING INTERIOR INDICATION,098458 EXCEPT FOR 097575-097589,098047-098056,098143,098162-098167,098174-098177,098196,098327,098362-098367,098416, 098417,098424. ALSO INSTALLED ON 098588,098589.
221
COVERING INTERIOR INDICATION FA. LAWO
221
COVERING INTERIOR INDICATION,098459 ALSO INSTALLED ON 097575-097589,098047-098056,098143,098162-098167,098174-098177,098196,098327,098362-098367,098416, 098417,098424. EXCEPT FOR 098588,098589.
221
COVERING INTERIOR INDICATION
225
FLAP FRONT LEFT
225
FLAP FRONT LEFT, NO.7E23I.......I.......I I II
230
FLAP FRONT RIGHT, NO.7E23I.......I.......I I II
230
FLAP FRONT RIGHT
235
FASTENER
236
LOCK , STATE LOCK NUMBER WHEN ORDERING
236
LOCK HOUSING , STATE LOCK NUMBER WHEN ORDERING
237
LATCHHAPPICH
237
LATCH
237
LATCHTO A 000 988 56 60
254
KEY FILLER CAP, STATE LOCK NUMBER WHEN ORDERING
260
CONSOLE TRANSVERSE DUCT,TOP
265
CONSOLE LEFT
270
SPRING
270
SPRING
272
CONSOLE RIGHT
274
BRACKET
278
BRACKET
278
BRACKET
870
PLATE
872
SCREW , Replaced By: N007985006193
874
SCREW INSTRUMENT PANEL TO COWL
876
WASHER
878
NUT
880
NUT BATTERY CABLE MOUNTING,5 193595
882
WASHER COMPRESSED AIR LINE TO BRACKET
884
SCREW PUMP TO BRACKET
886
ANGLE
888
ANGLE
890
TAPPING SCREW3,5X16MM
892
INSULATION
894
ADHESIVE TAPE SEAL TO BODY, ORDER BY THE METER
896
RUBBER BUFFER FLAP TO LEVER, NO.8316INO.7C52INO.9051I I II I
898
NUT , Replaced By: N913023006001
900
NUT RETAINER REAR SEAT BENCH BACKREST TO REAR PANEL
904
ADHESIVE TAPE , ORDER BY THE METER
999
FRAME TRANSVERSE DUCT,BOTTOM
999
FRAME TRANSVERSE DUCT,TOP
999
FLAP , NO.7C01I.......I.......I I II
999
BRACKET EMERGENCY EXIT IN ROOF
999
BRACKET EMERGENCY EXIT IN ROOF
