Поз.
Артикул
Описание
5
BATTERY
5
BATTERY FILLED AND CHARGED 12V / 200 AH, STATE INDEX 64 WHEN ORDERING
5
BATTERY
5
BATTERY12V / 50AH
5
BATTERY
5
STARTER BATTERY12V / 210AH
5
BATTERY MAINTENANCE-FREE 12V/200 AH, SA 67062/01
5
BATTERY PARTS KIT,5 419106
5
BATTERY MAINTENANCE-FREE 74 AH/12V
5
BATTERY
11
VENT BATTERY COVER
14
SEAL RING BATTERY COVER
15
HOSE BATTERY VENTING 11 X 2 MM, ORDER BY THE METER
17
GROMMET CAB ROOF
17
GROMMET , Replaced By: A0009972081
20
CLAMP
20
CLAMP LINE MOUNTING
23
SCREW COVER PLATE TO COVER PLATE M 6 X 12
26
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
29
NUT SPRING-LOADED PUSH ROD
32
ELECTRIC CABLE FROM BATTERY POS.POLE TO STARTING MOTOR 70 MM2, ORDER BY THE METER
32
ELECTRIC CABLE FROM BATTERY MASTER SWITCH TO CABLE CONNECTOR
35
SOLDERING TERMINAL POS. POLE
35
SOLDERING TERMINAL BATTERY POS. POLE 70 MM2
35
SOLDERING TERMINAL BATTERY NEG. POLE 70 MM2
35
SOLDERING TERMINAL NEG.POLE
41
CABLE SHOE BATTERY CABLE 10-70 MM
41
CABLE LUG WITH BORE 8.4MMX70MM2
44
CONNECTOR BATTERY CABLE
50
SCREW SHIFT CASE TO SLOTTED GATE
53
SPRING WASHER PROTECTIVE PLATE TO BELL HOUSING
56
LOCK WASHER FUSE
59
NUT BATTERY CABLE
60
CABLE HARNESS FROM CHARGER TO BATTERY
60
ELECTRICAL WIRING HARNESS CHARGING PLUG SOCKET
61
SCREW CONNECTION TO PLUG THE BORES,5 097182
65
CHARGER BATTERY
90
CABLE HARNESS BATTERY COMPARTMENT,102109
95
ELECTRIC CABLE FROM BATTERY I NEG. POLE TO BATTERY II POS. POLE
100
CABLE HARNESS BATTERY CUT-OFF
105
CABLE HARNESS BATTERY CUT-OFF 70MM2,1350MM, Replaced By: N072551070880, +001A0005461830, +001A0005460135, +002A0009970881, +001N043234008007, +001N046234010007
105
ELECTRIC CABLE , Replaced By: N922002070000
108
BRACKET BATTERY CUT-OFF
111
NUT , Replaced By: N913023006001
114
HEXALOBULAR BOLTM5X12
117
HOUSING COVER , AS OF PRODUCTION BREAKPOINT (DISCONTINUATION DATE FOR BCS) 01.03.2012
120
NUT LOCK TO COVER
