Поз.
Артикул
Описание
3
CATALYST
3
CATALYST
3
PARTICULATE CONVERTER
4
SENDER UNIT TEMPERATURE SENSOR,EXHAUST
5
NUT. CLAMPING RING
6
EXHAUST PIPE , AS OF PRODUCTION BREAKPOINT DATE 15.02.08
6
EXHAUST PIPE
6
EXHAUST PIPE , UNTIL PRODUCTION BREAKPOINT DATE 14.02.08
6
EXHAUST PIPE , Replaced By: A6284903319
7
EXHAUST PIPE AT MUFFLER 120 MM, FROM IDENT NO. 097921
8
REAR EXHAUST PIPE
10
END PIECE , Replaced By: A3574921314
14
BRACKET
16
BRACKET , UNTIL PRODUCTION BREAKPOINT DATE 28.02.09
16
BRACKET
17
BRACKET , UNTIL PRODUCTION BREAKPOINT DATE 28.02.09, Replaced By: A6284905340
17
BRACKET , UNTIL PRODUCTION BREAKPOINT DATE 28.02.09
18
BRACKET
18
BRACKET , UNTIL PRODUCTION BREAKPOINT DATE 28.02.09
19
HEXAGON HEAD BOLT
20
PROTECTIVE PLATE
21
PROTECTIVE PLATE
24
DASHPOT
24
INSULATION
28
BLIND RIVET. RIVET NAME PLATE TO BRACKET
30
CLAMP EXHAUST SYSTEM D124,5MM, Replaced By: A6554920140
30
CLAMP , Replaced By: N071555124501
31
CLAMP
31
CLAMP FLEXIBLE METAL TUBE TO CONNECTOR AND TO COLLAR
34
HEXAGON HEAD BOLT AUTOMATIC TRANSMISSION AT ENGINE M10X60
34
HEXAGON HEAD BOLT BRACKET TO DISTRIBUTOR
35
SCREW. HEXAGON HEAD BOLT , Replaced By: N910143008005
35
HEXAGON HEAD BOLT. SCREW CABLE HARNESS TO BRACKET M8X40
35
SCREW SHIFT LEVER TO BRACKET M8X30
35
SCREW BRACKET TO SIDE MEMBER M10X35
36
HEXAGON HEAD BOLT RESONATOR TO TRANSMISSION CASE,K 138633
36
HEXAGON HEAD BOLT. SCREW BRACKET TO SIDE MEMBERM 12X1.5X30
37
SCREW CLAMP TO EXHAUST PIPE
40
SCREW , Replaced By: N910143008002
41
SCREW SHIFT LEVER TO BRACKET M8X30
45
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
46
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
46
NUT HORN TO BRACKET M8
46
NUT ENGINE MOUNTING M8
46
HEXAGON NUT. NUT , Replaced By: N913023008002
47
NUT HORN TO BRACKET M8
48
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
48
NUT BRACKET TO SIDE MEMBER M12X1.5
68
BRACKET , UNTIL PRODUCTION BREAKPOINT DATE 28.02.09
68
BRACKET , AS OF PRODUCTION BREAKPOINT DATE 01.03.09
68
BRACKET , UNTIL PRODUCTION BREAKPOINT DATE 28.02.09, Replaced By: A6284905640
70
BRACKET , AS OF PRODUCTION BREAKPOINT DATE 01.03.09
70
BRACKET , UNTIL PRODUCTION BREAKPOINT DATE 28.02.09
92
HEXAGON HEAD BOLT. SCREW BRACKET TO SIDE MEMBER M10X25
140
SCREWTO A957 490 05 14
141
SEAL RING
233
WASHER PUMP TO CONSOLE
236
HEXAGON HEAD BOLT
243
THREADED PLATE , AS OF PRODUCTION BREAKPOINT DATE 01.03.09
246
BRACKET , AS OF PRODUCTION BREAKPOINT DATE 01.03.09
272
HEAT SHIELD , AS OF PRODUCTION BREAKPOINT DATE 01.03.09
275
BRACKET , AS OF PRODUCTION BREAKPOINT DATE 01.03.09
