Поз.
Артикул
Описание
89
HOSE HEATING FEED
89
HOSE FROM AUXILIARY HEATER TO HEAT EXCHANGER
92
HOSE HEATING FEED
95
RUBBER RING
98
HOSE BETWEEN WATER VALVE AND RECIRCULATING PUMP
98
HOSE BETWEEN WATER VALVE AND RECIRCULATING PUMP
101
HOSE FROM VALVE TO HEAT EXCHANGER
101
HOSE FROM VALVE TO HEAT EXCHANGER,188121
101
HOSE , Replaced By: A6388327923
104
HOSE FROM RETURN LINE TO WATER PUMP
104
HOSE FROM RETURN LINE TO WATER PUMP
105
HOSE BRACKET FEED LINE AND RETURN LINE 23-30 MM
107
LOOM TIE HOSE FASTENING
107
CLAMP , Replaced By: N000000000667
110
CLAMP25-40X13 MM
113
BRACKET FEED HOSE TO FIRE WALL
116
NUT ,230416
119
WASHER FUSE TO FUSE BOX
122
CABLE STRAP LINE MOUNTING 260X3.3MM
125
RECIRCULATING PUMP. PUMP , NOT FOR AUSTRALIA
128
BRACKET FEED HOSE TO FIRE WALL
131
BRACKET FEED LINE
140
CLIP HOSE FASTENING
140
CLAMP , Replaced By: A6389880878, +001A0009953765
143
CLAMP , Replaced By: A0009956265
144
HOSE BRACKET FEED LINE AND RETURN LINE 23-30 MM
144
CLAMP , Replaced By: A0009956265
146
BRACKET HEATING WATER VALVE
149
BRACKET HEATING WATER VALVE
152
VALVE SUPPLIER: MESSRS. BOSCH, F 125158 EXCEPT CODE 805 ALSO INSTALLED IN VEHICLE TO F 125157 WITH CODE 806
155
RUBBER BUFFER WATER VALVE TO BRACKET
158
RUBBER BUFFER BETWEEN BRACKET AND DOUBLE WATER VALVE
161
NUT
164
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
167
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
170
WASHER PLUG SOCKET TO BRACKET
191
PIN BUSHING HOUSING BIPOLAR
194
ROUND PIN BUSHING WITH DETENT AND WITH CATCH FOR HOUSING 2.5 MM2
999
HOSE RETURN LINE TO WATER PUMP
999
HOSE HEATING FEED
