Поз.
Артикул
Описание
8
INSULATING HOSE ELECTRIC CABLE THRU FRAME
8
INSULATING HOSE ELECTRIC CABLE THRU FRAME
8
INSULATING HOSE ELECTRIC CABLE THRU FRAME
8
INSULATING HOSE ELECTRIC CABLE THRU FRAME
16
BRACKET LEFT COMPRESSED AIR LINES
16
BRACKET RIGHT COMPRESSED AIR LINES
24
BRACKET AT CAB BEARING BRACKET
24
BRACKET AT CAB BEARING BRACKET
24
BRACKET ACCORDION TUBE
24
BRACKET ACCORDION TUBE
24
BRACKET COMPRESSED AIR LINE TO ENGINE BEARING BRACKET
24
BRACKET COMPRESSED AIR LINE TO ENGINE BEARING BRACKET
32
SCREW , Replaced By: N304017008021
32
SCREW PIPE CLAMP
40
SCREW END PIECE TO EXHAUST PIPE M 12X30
40
SCREW , Replaced By: N304017012020
48
NUT , Replaced By: N913004008001
48
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
56
NUT SUPPORT TO SIDE MEMBER
64
BRACKET LINE TO FRONT PANEL
72
BRACKET TO LOCK ELECTRIC LEAD-IN
999
BRACKET LEFT COMPRESSED AIR LINES, Replaced By: A6554303310
999
BRACKET RIGHT COMPRESSED AIR LINES, Replaced By: A6554303410
999
BRACKET , Replaced By: A6154200086
999
INSULATING HOSE ELECTRIC CABLE THRU FRAME
