Поз.
Артикул
Описание
10
FRONT FENDER LEFT, 100000
20
LOCK PANELLING TO FRONT FENDER,BOTTOM
22
FRONT PART
26
SCREW INTERMEDIATE BEARING TO BRACKET M 8X20
42
LOCK
44
SHEET METAL SCREW6.3X16
46
WASHER
51
PAD 2 MM
53
LOCK
55
SCREW ACCELERATOR PEDAL TO CAB M 6 X 20
57
SCREW BRACKET TO AIR INTAKE PIPE
59
WASHER
61
WASHER
63
PAD RIGHT
65
RUBBER BUFFER
65
RUBBER BUFFER , Replaced By: A1269870139
67
LOCK
69
SHEET METAL SCREW , Replaced By: A0009906836
72
SCREW FRONT FENDER TO FRONT PANEL PILLAR
74
LOCK
80
ADHESIVE TAPE (SEAL),BETWEEN OUTSIDE REAR PILLAR AND ROOF 560 MM, ORDER BY THE METER
82
GARNISH MOULDING LEFT
85
GARNISH MOULDING LEFT
85
SEAL , Replaced By: A1148800182
87
FASTENER BUTTON
89
FASTENER BUTTON
89
GROMMET , Replaced By: A0019882081
89
FASTENER BUTTON , Replaced By: A0089970381
89
FASTENER BUTTON. GROMMET , Replaced By: A0019882081
110
PARTITION PANEL LEFT
115
SEAL 770 MM ORDER BY THE METER
118
SEALING CORD PAINT RUN-OFF HOLE IN REAR WINDOW OPENING, ORDER BY THE METER
127
FRONT BUMPER FACE BAR LEFT, FROM CHASSIS: 010 105069 110 277259
142
REINFORCEMENT , FROM CHASSIS: 010 105672 110 277011
144
BUMPER JOINT COVER
147
SCREW BRACKET TO FENDER,K 104588
160
RAIL3100 MM
160
RAIL , Replaced By: A1158850021
166
BUMPER GUARD LEFT, FROM CHASSIS: 010 105672 110 277011
170
BUFFER
172
RUBBER SECTION60 MM, ORDER BY THE METER
181
NUT
189
SPACER TUBE , Replaced By: A1149910140
189
SPACER TUBE HOSE TO FITTING,5 709892-5 7245835 800308-5 801937
196
BRACKET LEFT, 100000
206
FRONT BUMPER FACE BAR
208
RAIL
217
SPACER TUBE
234
BRACKET LEFT, FROM CHASSIS: 073 002705-100000
252
BRACKET FRONT, FROM CHASSIS: 010 105672 110 277011 ALSO INSTALLED ON: 275349,275350,276194,276195,276539,276540,276823,276869,276871,276879,276880,276885,276886,276895, 276928,276964,276969.
262
PLUG
265
RUBBER RING
269
PLUGTO 123 880 12 70
999
SCREW , Replaced By: N910105006002
999
NUT , Replaced By: N913012006001
999
NUT , Replaced By: N913019006000
999
NUT CLAMP TO BRACKET
999
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
999
HEXAGON HEAD BOLT
999
SCREW BRACKET TO SIDE MEMBER
999
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
999
SCREW PUMP TO BRACKET
999
WASHER BRACKET TO COVERING
999
WASHER BRACKET TO LEFT SIDE MEMBER
999
WASHER COLD START SYSTEM TO BRACKET
999
WASHER COMPRESSED AIR LINE TO BRACKET
999
WASHER , Replaced By: N009021006208
999
SCREW
999
SCREW ELECTRIC CABLE TO FUSE BOX
999
SHEET METAL SCREW ELECTRIC CABLE TO FIRE WALL
999
SHEET METAL SCREW BOOT TO CAB FLOOR
999
SHEET METAL SCREW COVER AND BRACKET TO CAB CORNER PILLAR
999
SHEET METAL SCREW BRACKET TO FLOOR PLATE, Replaced By: N000000000460
999
SHEET METAL SCREW BRACKET TO CAB 4,2X13
999
SHEET METAL SCREW HOSE TO FIRE WALL
999
SHEET METAL SCREW , NOT USED
999
SHEET METAL SCREW BRACKET TO WINDOW SILL
999
SHEET METAL SCREW BRACKET TO CAB FLOOR
999
WASHER , UP TO TRANSMISSION: 023 766040 UP TO CHASSIS: 009860
999
NUT BRACKET TO RETARDER
999
NUT BALL PIVOT TO LEVER
999
NUT TACHOGRAPH TO BRACKET
999
NUT AIR INTAKE PIPE TO AIR INTAKE PIPE,937184
999
SCREW GROUND STRAP TO CAB CROSS MEMBER M 10X25
999
SCREW , Replaced By: N304017008034
999
SCREW , Replaced By: N304017008016
999
WASHER BOOT TO CAB FLOOR
999
WASHER AS REQUIRED 1.0 MM, ON BUSES UP TO CHASSIS 053510,ON TRUCKS UP TO CHASSIS 209647,FROM CHASSIS SEE 766.3
999
SPRING WASHER , Replaced By: N000137008212
999
SPRING WASHER ALTERNATOR CONNECTION D+
999
LOCK WASHER , Replaced By: N912004010102
999
WASHER RADIATOR TO RUBBER MOUNTING
999
WASHER , Replaced By: N000125010532
999
WASHER , Replaced By: N000125008443
999
WASHER COVER PLATE TO COVER PLATE
999
WASHER COMPRESSED AIR LINE TO BRACKET
999
WASHER , Replaced By: N000433005304
999
WASHER BRACKET TO SUPPORT
999
WASHER , Replaced By: N000125004319
999
SHEET METAL SCREW BRACKET TO FLOOR PLATE
999
LOCK INSTRUMENT PANEL TO COWL
999
REPAIR KIT , Replaced By: A1148800597
999
REPAIR KIT , Replaced By: A1148800497
999
PLUG
999
MOUNTING , Replaced By: A1078850020
999
MOUNTING , Replaced By: A1078850020
999
REAR BUMPER FACE BAR RIGHT
999
BUMPER GUARD RIGHT
999
CUP RIGHT
999
CUP RIGHT
999
BUMPER GUARD FRONT RIGHT
999
CUP , Replaced By: A1168800761
999
BOX , Replaced By: A1168800661
999
CUP , Replaced By: A1168800561
999
CLAMP WIRE CABLE TO FIRE WALL
999
LOCK , Replaced By: A1159940121
999
WASHER , Replaced By: A1089900340
999
PLUG AIR DUCT TO CAB
999
GRILLE , Replaced By: A1158880523
999
GARNISH MOULDING , Replaced By: A1168880185
999
RADIATOR GRILLE SHELL , FROM CHASSIS: 015 200001 110 400001 115 200001 005,017,105,107,108,117,119 000001 EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO CHASSIS: 005,017 044524 015 262194 105,107,108,117,119 082984 110 444284 114 012374 115 277300, Replaced By: A1158880615
999
GRILLE RIGHT
999
SPRING , Replaced By: A1158880334
999
TOW HOOK , Replaced By: A1155860288
999
ESCUTCHEON , Replaced By: A1155860288
999
MERCEDES STAR , Replaced By: A1155860188
999
SEAL , Replaced By: A1158870298
999
PLATE , Replaced By: A1089900340
999
PARTITION PANEL RIGHT, FROM CHASSIS: 000,002,010 000270 015 000142 100,102,103,110,112 000682 115 000300 FROM CHASSIS 005,017,105,107,108,117,119 000001
999
PARTITION PANEL , Replaced By: A1158840635
999
PAD RIGHT
999
PAD , Replaced By: A0039895485
999
PAD , Replaced By: A1158810997
999
FRONT BUMPER FACE BAR FRONT RIGHT
999
FRONT BUMPER FACE BAR RIGHT
999
FRONT FENDER , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO CHASSIS 005,017 015652 015 222251, Replaced By: A1158801018
999
FRONT FENDER RIGHT, UP TO CHASSIS: 015 200000 110 400000 115 200000
999
ENERGY-ABSORBING UNIT , UP TO CHASSIS: 017 006290 117 010264, Replaced By: A1158800514, +002A1168850042
999
ENERGY-ABSORBING UNIT , UP TO CHASSIS: 017 006290 117 010264, Replaced By: A1158800314, +002A1168850042
999
ENGINE HOOD , Replaced By: A1158801157, +001A1078800060, +002N914126006001
999
BUMPER GUARD RIGHT, FROM CHASSIS: 010 105672 110 277011
999
FRONT FENDER RIGHT, FROM CHASSIS: 015 200001 110 400001 115 200001 005,017,105,107,108,117,119 000001
999
BRACKET RIGHT
999
SEAL REPAIR KIT
999
ENGINE HOOD , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO CHASSIS 005,017 015652 015 222251, Replaced By: A1158801057
999
RADIATOR GRILLE SHELL , FROM CHASSIS: 005,017 044525 015 262195 105,107,108,117,119 082985 110 444285 114 012375 115 277301
999
MERCEDES BADGE , FROM CHASSIS: 007,008,015,017 200001 FROM CHASSIS: 011 100001 FROM CHASSIS: 060,062 100001 UP TO CHASSIS: 007,008,015,017 242032 011 107854 060 117097 062 106865
999
COVERING FRONT RIGHT
999
ROCKER PANEL RIGHT
999
ENGINE HOOD CATCH
999
MERCEDES BADGE , Replaced By: A1158800188
999
FRONT FENDER , Replaced By: A1155860088
999
REPAIR KIT , Replaced By: A1158800997
999
BRACKET RIGHT, FROM CHASSIS: 073 002705-100000
999
REAR BUMPER FACE BAR RIGHT
999
SEAL RADIATOR GRILLE SHELL MOUNTING MATERIAL, FROM CHASSIS: 005,017 044525 015 262195 105,107,108,117,119 082985 110 444285 114 012375 115 277301
999
SEAL RADIATOR GRILLE SHELL MOUNTING MATERIAL, FROM CHASSIS: 015 200001 110 400001 115 200001 005,017,105,107,108,117,119 000001 UP TO CHASSIS: 005,017 044524 015 262194 105,107,108,117,119 082984 110 444284 114 012374 115 277300
999
BRACKET RIGHT, FROM CHASSIS: 073 002705-100000
999
SEAL RADIATOR GRILLE SHELL MOUNTING MATERIAL, UP TO CHASSIS: 015 200000 110 400000 115 200000
999
SEAL , Replaced By: A1148800282
999
GARNISH MOULDING RIGHT
999
REPAIR KIT , Replaced By: A1238800997
999
REPAIR KIT , Replaced By: A1238800897
999
REPAIR KIT , FROM CHASSIS: 007,008,015,017 242033 011 107855 060 117098 062 106866 EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO CHASSIS: 007,008,015,017 257476 011 110343 060 121219 062 108533, Replaced By: A1145860588
999
REPAIR KIT , Replaced By: A1145860488
999
GARNISH MOULDING , Replaced By: A1168880185
999
LEVER RIGHT, 000,001,004,010 FROM CHASSIS 108183,100,101,104,110 FROM CHASSIS 180688
999
ENGINE HOOD CATCH , Replaced By: A1158800160
999
ENGINE HOOD CATCH , Replaced By: A1158870006
999
SUPPORT RIGHT
999
WASHER PROTECTIVE PLATE TO BRACKET,5 502998
999
SPRING , Replaced By: A1085860088
999
REPAIR KIT , Replaced By: A1155860288
999
MOUNTING LEFT TOP AND RIGHT BOTTOM
999
ADHESIVE TAPE AS REQUIRED 1850 MM, ORDER BY THE METER
999
CLIP , Replaced By: A0019942745
999
CLIP , Replaced By: A0019942745
999
ADHESIVE TAPE , Replaced By: A0019875646
999
LOCK GRILLE TO RADIATOR GRILLE SHELL,TOP LATERAL
999
PIN , Replaced By: N918001005001
999
ADHESIVE TAPE , Replaced By: A0019875646
999
CLIP , Replaced By: A0029888578
