Поз.
Артикул
Описание
4
FOLDING ARMREST , STATE COLOR NUMBER WHEN ORDERING
5
FOLDING ARMREST , STATE COLOR NUMBER WHEN ORDERING
6
FOLDING ARMREST
8
SUPPORT WITH MOLDED PART
9
COVER , STATE COLOR NUMBER WHEN ORDERING
11
MOUNTING MATERIAL
13
SUPPORT
19
TOOTHED WASHER SENDER UNIT TO BRACKET
20
NUT USED WITH LEATHER AND VELOURS TRIM, 123 297292 133 002319
28
SPACER ARMREST TO SUPPORT
29
INSULATING HOSE PRESSURE REGULATOR,ANTI-FREEZE DEVICE, ORDER BY THE METER
30
WASHER ARMREST TO SUPPORT
30
WASHER , Replaced By: A1169840156
31
WASHER REAR PANEL,TOP,HAT TRAY
32
RUBBER RING ARMREST TO SUPPORT
33
NUT ARMREST TO SUPPORT
33
NUT , Replaced By: A1099900160, +001A1099900001
34
SCREW , Replaced By: N000933005036
34
SCREW SHUT-OFF VALVE TO BRACKET
34
SCREW
36
PLATE , Replaced By: A1239730511
36
PLATE
38
RAIL , Replaced By: A1169730127, +001A0009908891
38
RAIL , FROM CHASSIS:115.015 284183 115.017 062675 115.110 455207 115.114 028994 115.115 310978 115.117 102601
41
SCREW COVER PLATE TO COVER PLATE M 6 X 10
41
SCREW
41
SCREW , Replaced By: N304017006034
43
TOOTHED WASHER MASKED STOP LAMP
46
NUT RETAINER , Replaced By: A3229900091
46
NUT RETAINER , Replaced By: A0009907191
999
SEALING CORD600 MM, COLOR NO.: FOR TYPES 100,107,114,115 SEE PASSENGER CAR EQUIPMENT MANUAL,FOR TYPE 116, SEE FOOTN. 95 ORDER BY THE METER
999
NUT RETAINER USED WITH IMITATION LEATHER TRIM, 123 297291 ALSO INSTALLED ON 306113-347407 133 002318 ALSO INSTALLED ON 004116-012658
999
WELT1X900MM,1X920MM
999
PLATE , FROM CHASSIS:114.010 016431 114.015,017 013597 115.010 014485 115.015 011502 115.110,112 031352 115.115 013966
999
COVER , STATE COLOR NUMBER WHEN ORDERING
999
COVER , STATE COLOR NUMBER WHEN ORDERING
999
FOLDING ARMREST , STATE COLOR NUMBER WHEN ORDERING
999
COVER
999
COVER , STATE COLOR NUMBER WHEN ORDERING
999
COVER
999
FOLDING ARMREST
999
SUPPORT , Replaced By: A1159703620, +001A1159132728, +002N007987006176
999
FOLDING ARMREST
999
FOLDING ARMREST
999
GARNISH MOULDING
999
GARNISH MOULDING
999
FOLDING ARMREST COMPLETE,BUT LESS COVER
999
MOUNTING MATERIAL
999
FOLDING ARMREST , Replaced By: A1159702430
999
MOUNTING MATERIAL
999
SUPPORT , FROM CHASSIS:114.010 063514 114.011 005103 114.015,017 080001 114.021 006200 114.022 015595 114.023 004234
999
SCREW , Replaced By: N007988006169
999
SCREW
999
WASHER , UP TO CHASSIS: 017 029988 114 000523 117 064694
999
NUT CYLINDER TO BRACKET TO0002902112
999
SCREW
999
NUT BATTERY MOUNTING
999
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
