Поз.
Артикул
Описание
5
RESERVOIR EXPANSION TANK
8
LOCKING CAP
14
STRAINER
17
CAP RESERVOIR DE-AERATION
20
MASTER CYLINDER CLUTCH
21
INTERMEDIATE PIECE
22
PLUG
23
CYLINDER. REPAIR KIT CLUTCH MASTER CYLINDER
24
SCREW COVER PLATE TO BRACKET
26
SPRING WASHER LICENSE PLATE TO BRACKET
29
ROD CLUTCH MASTER CYLINDER
32
NUT
32
NUT , Replaced By: N304035008001
35
ARTICULATION PIECE CLUTCH MASTER CYLINDER
35
ARTICULATION PIECE CLUTCH MASTER CYLINDER
38
NEEDLE BEARING JOINT TO PIN
38
NEEDLE BEARING JOINT TO PIN
38
NEEDLE BEARING JOINT TO PIN
38
NEEDLE BEARING JOINT TO PIN
41
WASHER BRACKET TO FENDER BRACKET
44
LOCK PLATE PUSH ROD TO CLUTCH PEDAL
47
PIN CLUTCH MASTER CYLINDER TO CLUTCH PEDAL
50
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
50
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
50
NUT , Replaced By: N913004008001
53
HOSE FROM RESERVOIR TO MASTER CYLINDER, ORDER BY THE METER
56
LINE FROM MASTER CYLINDER TO PARTITION FITTING 1680 MM,5 582441K 130132
56
LINE FROM MASTER CYLINDER TO HYDRAULIC LINE
56
LINE FROM MASTER CYLINDER TO HYDRAULIC LINE 1345 MM,5 486055
59
LINE FROM HYDRAULIC LINE TO CONNECTION FITTING 2000 MM, NOT USED
59
LINE , NOT USED, Replaced By: A3812902214
62
LINE FROM VALVE TO CONNECTION FITTING,K 172343 ORDER BY THE METER
66
LINE FROM MASTER CYLINDER TO HOSE 95 MM,K 130133
68
UNION NUT
68
UNION NUT LINE CONNECTION
71
GLAND LINE CONNECTION
72
LINE FROM MASTER CYLINDER TO PARTITION FITTING 5000 MM
72
LINE FROM MASTER CYLINDER TO PARTITION FITTING 4150 MM
73
LOOM TIE LINE MOUNTING
74
FITTING (PARTS KIT),LINE RUPTURE
77
ELBOW FITTING BETWEEN THE LINES,K 130132
80
SLAVE CYLINDER CLUTCH ACTUATION, NOT USED
82
CLUTCH BOOSTERKNORR, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
82
CLUTCH BOOSTERWABCO,K 037847 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
82
CLUTCH BOOSTER ,K 037846, Replaced By: A0002951418
87
REPAIR KIT CLUTCH BOOSTER KNORR
87
REPAIR KIT CLUTCH BOOSTER WABCO
88
BRACKET HYDRAULIC LINE TO FAN SHROUD
89
COVER PLATETO 000 295 02 18 , 000 295 09 18
90
BRACKETWABCO,K 037846
92
SCREW FLANGE TO BELL HOUSING M 10X25,5 962906
94
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
95
FITTING CLUTCH BOOSTER,CONNECTION: "4"
95
FITTING , Replaced By: A0029909768
98
BRACKET LINE TO FRONT PANEL
99
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
101
BRACKET HYDRAULIC LINE TO ENGINE MOUNTING, NOT USED
102
BRACKET LINE MOUNTING
111
FITTING HYDRAULIC LINE TO BRACKET,K 130132
112
ANGLE LINE MOUNTING
112
ANGLE LINE MOUNTING
113
BRACKET HYDRAULIC LINE TO BELL HOUSING,5 547965K 130132
114
BRACKET FUEL LINE TO BELL HOUSING
115
CLAMP IDLING ADJUSTMENT WIRE CABLE,K 147121
115
CLAMP IDLING ADJUSTMENT WIRE CABLE,K 147121
115
CLAMP ,K 147121, Replaced By: N000000000319
116
CLAMPING PIECE IDLING ADJUSTMENT WIRE CABLE
117
SCREW PUMP TO BRACKET
117
SCREW , Replaced By: N304017006016
119
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
122
NUT PUMP TO BRACKET
999
SCREW , Replaced By: N000000001149
999
BRACKET ,5 4119215 411922K 037846, Replaced By: A3562950240, +001N000908016001, +002N914126010052
999
BRACKET BRACKET TO FAN SHROUD BRACKET,K 130132
999
BRACKET WIRE CABLE TO FRAME SIDE MEMBER
999
HEXALOBULAR BOLT WIRE CABLE TO BRACKET
999
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
999
WASHER COMPRESSED AIR LINE TO BRACKET
999
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "22"
999
SCREW , Replaced By: N304017006020
999
SCREW END PIECE TO EXHAUST PIPE M 10X25
999
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
999
SEAL RING COMPRESSED AIR LINE TO CLUTCH BOOSTER WABCO
999
SCREW , Replaced By: A0029903712
999
NUT FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
999
SCREW LICENSE PLATE TO BRACKET
999
NUT STRAP TO BRACKET
999
NUT , Replaced By: N913004006001
999
NUT , Replaced By: N910113010000
999
SCREW CLUTCH BOOSTER TO BELL HOUSING,K 037846
999
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
999
CLAMP LINE MOUNTING
