Поз.
Артикул
Описание
5
PLASTIC PIPE AERATION, ORDER BY THE METER
10
FITTING (PARTS KIT),LINE RUPTURE
10
FITTING , Replaced By: A0029905971
20
ELBOW FITTING HOSE WIDTH, 9 MM,TO M22
25
ELBOW FITTING , Replaced By: A0049905371
25
ELBOW FITTING HOSE WIDTH, 6 MM,TO M22
30
CONNECTOR , Replaced By: A0029905478
30
CONNECTOR HOSE WIDTH, 6 MM,TO M16
35
LOCK RING LINE CONNECTION
35
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
35
SEAL RING , Replaced By: A0009940747
45
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION
45
LOCK LINE CONNECTION
45
LOCK , Replaced By: A0009945448
60
REPAIR KIT COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 16
60
REPAIR KIT. TS SEALING RING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 22
60
REPAIR KIT , Replaced By: A0309971748
65
LOOM TIE LINE MOUNTING
70
VALVE (CHECK VALVE)
70
VALVE (CHECK VALVE)
70
VALVE (CHECK VALVE)
75
SEAL RING FUEL LINE TO FEED PUMP
80
SCREW. UNION SCREW LINE CONNECTION
80
SCREW. UNION SCREW , Replaced By: A0009973734
85
NUT LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
85
NUT LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
90
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
90
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
90
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940103
95
SEALING CORD COMPRESSED-AIR-LINE PLUG-CONNECTION
95
SEALING CORD COMPRESSED-AIR-LINE PLUG-CONNECTION
100
BRAKE LINE COUPLING SUPPLY "WABCO"
100
BRAKE LINE COUPLING SUPPLY "WABCO"
100
BRAKE LINE COUPLING SUPPLY "WABCO"
100
BRAKE LINE COUPLING SUPPLY "KNORR"
100
BRAKE LINE COUPLING SUPPLY "KNORR"
105
SEAL RING"WABCO"
110
REPAIR KIT"KNORR"
115
HOLLOW SCREW FUEL LINE TO FEED PUMP
115
HOLLOW SCREW , Replaced By: N915036010108
120
SEAL RING FUEL LINE TO FEED PUMP
130
BRACKET BRAKE LINE COUPLING
130
BRACKET BRAKE LINE COUPLING
135
CLAMPING SLEEVE
145
FITTING LOAD/NO-LOAD VALVE,CONNECTION: "40",5 509133
150
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
155
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
160
SCREW. UNION SCREW LINE CONNECTION
170
WASHER BRACKET TO CONSOLE
999
SCREW CLAMP TO BRACKET,5 597426
999
WASHER COMPRESSED AIR LINE TO BRACKET
999
WASHER , Replaced By: N009021006208
999
WASHER COMPRESSED AIR LINE TO BRACKET
999
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
999
BRACKET BRAKE LINE COUPLING,K 053740
999
BRACKET BRAKE LINE COUPLING
999
FITTING AIR DEHYDRATOR
999
SCREW , Replaced By: N910142008009
999
SCREW HOSE TO CAB M 6X25
999
NUT BRACKET TO BRACKET
999
NUT AT FILTER BRACKET
