Поз.
Артикул
Описание
5
BRAKE PRESSURE REGULATOR LOAD-DEPENDING BRAKE KNORR
5
BRAKE PRESSURE REGULATOR LOAD-DEPENDING BRAKE BOSCH
5
BRAKE PRESSURE REGULATOR LOAD-DEPENDING BRAKE WABCO, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
5
BRAKE PRESSURE REGULATOR LOAD-DEPENDING BRAKE BOSCH, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
5
BRAKE PRESSURE REGULATOR LOAD-DEPENDING BRAKE WABCO, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
5
BRAKE PRESSURE REGULATOR LOAD-DEPENDING BRAKE KNORR
8
REPAIR KIT BRAKE POWER REGULATOR KNORR
8
REPAIR KIT VALVE BOSCH
8
REPAIR KIT BRAKE POWER REGULATOR TO 002 431 05 12,KNORR
8
REPAIR KIT BRAKE POWER REGULATOR WABCO
8
REPAIR KIT COVERING BOSCH
8
REPAIR KIT , Replaced By: A0004300207
11
REPAIR KIT BRAKE POWER REGULATOR BOSCH
14
GUIDE SIGN LOAD-DEPENDING BRAKE,5 3072845 936365
14
GUIDE SIGN LOAD-DEPENDING BRAKE,5 936366
17
WASHER , Replaced By: N000125008443
17
WASHER EXHAUST MUFFLER TO STRAP
20
NUT , Replaced By: N913004008001
23
BRACKET BRAKE POWER REGULATOR
26
SCREW HOLLOW RUBBER SPRING TO CAB,5 956657
26
SCREW , Replaced By: N308676012026
26
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X35
32
WASHER BRACKET TO FRAME
35
NUT STRAP TO BRACKET
35
NUT , Replaced By: N910113010000
35
NUT SUPPORT TO SIDE MEMBER
47
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
50
HOLLOW SCREW FITTING LEFT AND RIGHT COMBINATION CYLINDERS, CONNECTION: "11,12",5 356525
53
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
56
LEVER BRAKE POWER REGULATOR CONTROL, TO BE ADAPTED DURING ASSEMBLY
59
PULL ROD FROM CONTROL SHAFT BEARING TO ENGINE SHAFT, TO BE ADAPTED DURING ASSEMBLY
62
CONNECTOR PULL ROD TO LEVER
65
CLAMP , Replaced By: N000000000665
65
CLAMP HOSE TO RADIATOR AND TO EXPANSION TANK 12-22X13 MM
68
CLAMP CONNECTOR TO BRAKE PRESSURE REGULATOR LEVER
71
BALL SOCKET BRAKE POWER REGULATOR CONTROL,5 574483
71
BALL SOCKET , Replaced By: A3579910622
71
BALL SOCKET PULL ROD
74
WASHER , Replaced By: N000125008443
74
WASHER EXHAUST MUFFLER TO STRAP
77
COTTER PIN CONNECTOR TO BRAKE PRESSURE REGULATOR LEVER
80
NUT
83
METAL SPRING BELLOWS BRAKE POWER REGULATOR CONTROL,5 557360K 049885
86
SCREW AT ENGINE MOUNTING,TO MOUNT LINES
89
LOCK WASHER FITTING TO BRACKET
90
BRACKET BRACKET TO REAR AXLE HOUSING
104
SCREW , Replaced By: N914112010002
104
SCREW BRACKET TO REAR AXLE HOUSING
999
SCREW. UNION SCREW , Replaced By: A0009973734
999
SCREW. UNION SCREW LINE CONNECTION
999
SCREW. UNION SCREW LINE CONNECTION
999
ADHESIVE FOIL GUIDE SIGN
