Поз.
Артикул
Описание
25
UNION NUT LINE CONNECTION,5 999999K 040105
34
GLAND , Replaced By: A0019901667
178
ELBOW FITTING 3/2-WAY VALVE BREATHING
199
BANJO UNION HOSE WIDTH, / I.D., 4/10 MM
214
BANJO UNION HOSE WIDTH, / I.D., 6/12 MM
214
BANJO UNION HOSE WIDTH, / I.D., 4/16 MM,5 999999K 040105
214
BANJO UNION HOSE WIDTH, / I.D., 6/16 MM
230
VALVE (3/2-WAY SOLENOID VALVE) WABCO
239
SEAL RINGWABCO
248
SEAL RINGWABCO
257
SEAL RINGWABCO
266
VALVE PARTWABCO
275
HOLLOW SCREW HEATING CONNECTION
278
FITTING LINE CONNECTION
281
SCREW. UNION SCREW , Replaced By: A0009973734
281
SCREW. UNION SCREW LINE CONNECTION
284
SEAL RING LINE CONNECTION
293
BRACKET SOLENOID VALVE,5 7668945 800000-5 806949
302
SCREW , Replaced By: N304017006016
302
SCREW PUMP TO BRACKET
311
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
320
BRACKET ,5 7668945 800001-5 806949, Replaced By: A3604292940
320
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT
329
SCREW REAR AXLE REGULATING SOLENOID VALVE M 8X95
329
SCREW , Replaced By: N304017008016
329
SCREW , Replaced By: N304017008043
329
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
329
SCREW VALVE TO BRACKET M 8X55
347
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
347
NUT , Replaced By: N913004008001
356
VALVE. SHUTTLE VALVE (SHUTTLE VALVE) VOSS
356
SHUTTLE VALVE , THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE, Replaced By: A0044292444
356
VALVE , Replaced By: A0044291544
356
VALVE SHUTTLE VALVE, REPAIR IMPOSSIBLE
365
SCREW. UNION SCREW , Replaced By: A0009973734
365
SCREW. UNION SCREW LINE CONNECTION
365
SCREW. UNION SCREW LINE CONNECTION
374
SCREW , Replaced By: N304017008034
374
SCREW BRACKET TO CROSS CONNECTION STRUT
383
NUT , Replaced By: N913004008001
392
VALVE. SHUTTLE VALVE (SHUTTLE VALVE) VOSS
392
VALVE , Replaced By: A0044291544
401
SCREW. UNION SCREW LINE CONNECTION
410
BRACKET SHUTTLE VALVE
410
BRACKET SHUTTLE VALVE, NOT USED
419
SCREW PIPE CLAMP
419
SCREW , Replaced By: N304017008021
428
NUT , Replaced By: N913004008001
437
SCREW END PIECE TO EXHAUST PIPE M 10X25
446
WASHER RADIATOR TO RUBBER MOUNTING
446
WASHER UNDERRUN PROTECTION AND BRACKET TO FRAME
446
WASHER , Replaced By: N006902011102
446
WASHER , Replaced By: N000125010532
446
WASHER , Replaced By: N006902011100
455
NUT GUSSET PLATES AND REAR CROSS MEMBER TO SIDE MEMBERS
464
VALVE 3/2-WAY
473
SEAL RINGWABCO
482
SEAL RINGWABCO
491
SEAL RINGWABCO
500
VALVE PARTWABCO
509
HOLLOW SCREW HEATING CONNECTION
512
FITTING LINE CONNECTION
515
SCREW. UNION SCREW , Replaced By: A0009973734
515
SCREW. UNION SCREW LINE CONNECTION
518
SEAL RING LINE CONNECTION
527
HOLLOW SCREW FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
529
T-FITTING COMBINATION CYLINDER,CONNECTION: "12"
530
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
531
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
532
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
533
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
534
SEAL RING AIR RESERVOIR,CONNECTIONS: "24,34"
536
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
545
FITTING FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "20"
554
SCREW. UNION SCREW LINE CONNECTION
563
LOOM TIE LINE MOUNTING 280 MM
