Поз.
Артикул
Описание
5
GROMMET BATTERY CABLE TO BATTERY MASTER SWITCH
8
GROMMET FOR PASSAGE OF LINE
11
INSULATING HOSE PRESSURE REGULATOR,CONNECTION "3", ORDER BY THE METER5 148812
17
BRACKET BREATHER LINE TO SIDE MEMBER
20
SCREW , Replaced By: N304017008034
20
SCREW BRACKET TO CROSS CONNECTION STRUT
23
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
23
NUT , Replaced By: N913004008001
23
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
26
BRACKET COMPRESSED AIR LINE TO CAB
29
SHEET METAL SCREW BRACKET TO CAB
32
SPRING WASHER LICENSE PLATE TO BRACKET
35
BRACKET CABLE HARNESS
35
BRACKET LEFT
37
BRACKET COMPRESSED AIR LINE TO TRANSMISSION CASE
41
SCREW COVER PLATE TO COVER PLATE M 6 X 12
43
NUT BALL PIVOT TO LEVER
45
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
47
SCREW END PIECE TO EXHAUST PIPE M 10X25
49
NUT STRAP TO BRACKET
49
NUT , Replaced By: N910113010000
70
BRACKET LINE TO REAR AXLE, NOT USED
74
SCREW , Replaced By: N304017008039
74
SCREW PROTECTIVE PLATE TO EXHAUST PIPE
74
SCREW PROTECTIVE PLATE TO EXHAUST PIPE
75
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
77
BRACKET COMPRESSED AIR LINE
80
SCREW END PIECE TO EXHAUST PIPE M 10X25
83
WASHER , Replaced By: N006902011102
83
WASHER UNDERRUN PROTECTION AND BRACKET TO FRAME
83
WASHER , Replaced By: N006902011100
85
NUT , Replaced By: N910113010000
85
NUT STRAP TO BRACKET
89
LOOM TIE
92
LOOM TIE LINE MOUNTING
92
LOOM TIE LINE MOUNTING 280 MM
95
WASHER , Replaced By: N000125008443
95
WASHER EXHAUST MUFFLER TO STRAP
999
CLAMP BRAKE HOSE
999
HOSE COMPRESSED AIR GUIDE, REAR AXLE. 220 MM
999
CLAMP BRAKE HOSE
