Поз.
Артикул
Описание
5
PLASTIC PIPE RISING PIPE 4X6 MM
5
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
8
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
11
UNION NUT
14
SEAL CONE
14
GLAND , Replaced By: A0019901667
17
SLEEVE LEAK LINE
20
CONNECTOR COMPRESSED-AIR-LINE PLUG-CONNECTION
20
CONNECTOR , Replaced By: A0029905378
23
FITTING FROM PUMP TO CYLINDER
23
ELBOW FITTING FROM PUMP TO CYLINDER, Replaced By: N000000006197
26
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 16
29
LOCK RING LINE CONNECTION
29
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
29
SEAL RING , Replaced By: A0009940747
32
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION
32
LOCK LINE CONNECTION
32
LOCK , Replaced By: A0009945448
35
REPAIR KIT , Replaced By: A0309971748
35
REPAIR KIT. TS SEALING RING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 22
35
REPAIR KIT COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 16
38
ANGLE LINE MOUNTING
38
BRACKET SENSOR CABLE TO FRONT AXLE
41
LOOM TIE LINE MOUNTING
44
DISTRIBUTOR
47
SCREW CONNECTOR
50
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
50
WASHER COMPRESSED AIR LINE TO BRACKET
53
NUT PUMP TO BRACKET
53
NUT , Replaced By: N913004006001
56
SCREW. UNION SCREW LINE CONNECTION
59
SCREW. UNION SCREW , Replaced By: A0009973734
59
SCREW. UNION SCREW LINE CONNECTION
62
PLUG DISTRIBUTOR,CONNECTIONS: "03,04,05",TO M 16,5 766894
65
VALVE EXHAUST BRAKE 3/2-WAY VALVE BOSCH
65
VALVE EXHAUST BRAKE 3/2-WAY VALVE WABCO
68
CUP 3/2-WAY VALVE WABCO
71
REPAIR KIT 3/2-WAY VALVE BOSCH
71
REPAIR KIT 3/2-WAY VALVE WABCO
74
NUT SUCTION LINE TO OIL PUMP
77
SPRING WASHER AT CAB FLOOR
80
SCREW. UNION SCREW , Replaced By: A0009973734
80
SCREW. UNION SCREW LINE CONNECTION
83
PIPE SOCKET 3/2-WAY VALVE,CONNECTION: "30"
999
ELBOW FITTING
999
SEAL RING
999
CONNECTOR DISTRIBUTOR TO CAB
999
CONNECTOR DISTRIBUTOR OUTPUT, COMPRESSED AIR LINE PLUG CONNECTION
999
BRACKET DISTRIBUTOR TO CAB
999
WASHER BRACKET TO FRAME
999
SCREW , Replaced By: N304017006034
999
SCREW , Replaced By: N308676012026
999
SCREW COVER PLATE TO COVER PLATE M 6 X 10
999
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X35
999
NUT BRACKET TO FRAME SIDE MEMBER
