Поз.
Артикул
Описание
105
CONDENSER
110
VALVE , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0018306384
115
CAP
120
BUSHING CONDENSER TO RADIATOR
125
GROMMET CONDENSER TO RADIATOR
130
SCREW CAB FLOOR COVERING M 6X25
135
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
135
WASHER COMPRESSED AIR LINE TO BRACKET
140
NUT CONDENSER TO RADIATOR
145
SEAL , Replaced By: A1408350198
145
SEAL BETWEEN CONDENSER AND RADIATOR,TOP 80 MM
145
SEAL BETWEEN CONDENSER AND RADIATOR,TOP 112 MM, A 142206 TO BE ADAPTED DURING ASSEMBLY
155
SEAL BETWEEN CONDENSER AND RADIATOR 610 MM
160
BRACKET ADDITIONAL BLOWER TO ADDITIONAL BLOWER
165
SCREW. HEXAGON HEAD BOLT RELAY TO BRACKET M5X16
170
BRACKET LATERAL ADDITIONAL BLOWER
175
SCREW OIL LINE TO TRANSFER CASE
180
NUT BRACKET TO ANTENNA, ONLY USED WITH REAR END MOUNTINGA 001878
185
INTERMEDIATE LAYER ADDITIONAL BLOWER TO CONDENSER,A 496760
206
BRACKET CONDENSER TO RADIATOR
207
CLAMP CABLE HARNESS MOUNTING
207
CLAMP , Replaced By: N000000001045
208
SCREW COVER PLATE TO COVER PLATE M 6 X 12
209
FITTED WASHER
209
WASHER , Replaced By: N000988008024
210
GUIDE SIGN , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A2028176920
210
GUIDE SIGN REFRIGERANT R 134 A
