Поз.
Артикул
Описание
6
AIR CLEANER
12
FILTER ELEMENTTO A 376 090 81 04
15
SWITCH
21
SCOOP
24
INTAKE CASE
27
SCREW BRACKET TO SIDE MEMBER
30
NUT GUSSET PLATES AND REAR CROSS MEMBER TO SIDE MEMBERS
33
CLAMP INTAKE CASE TO CAB CONSOLE
36
SCREW CLAMPING BOLT TO BRACKET
39
NUT GUSSET PLATES AND REAR CROSS MEMBER TO SIDE MEMBERS
48
AIR INTAKE PIPE
51
AIR INTAKE PIPE
63
SCREW POWER CYLINDER TO BEARING BRACKET
72
WASHER TRAILER PLUG SOCKET TO BRACKET
78
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
81
HOSE AIR INTAKE PIPE TO TURBOCHARGER
86
HOSE AIR INTAKE PIPE TO AIR CLEANER
89
HOSE AIR INTAKE PIPE TO AIR CLEANER
92
HOSE 18-MM-DIA. LINE
95
CLAMP100-120
95
CLAMP
98
LOOM TIE. CLAMP
98
LOOM TIE. CLAMP AS REQUIRED
101
CLAMP , Replaced By: N000000000678
101
LOOM TIE
104
LOOM TIE AS REQUIRED
104
LOOM TIE AS REQUIRED
107
LOOM TIE AIR INTAKE HOSE TO CLAMP
