Поз.
Артикул
Описание
5
RESERVOIR FLUID RESERVOIR
8
FILLER CAPTO A 688 431 00 02
11
STRAINER
14
NUT CONTROL ARM TO REAR AXLE
17
MASTER CYLINDER CLUTCH M14X1,D 561822
17
MASTER CYLINDER , Replaced By: A0012959706
17
MASTER CYLINDER , Replaced By: A3882957206
20
PLUG
23
CYLINDER. REPAIR KIT REPAIR KIT TO 384 295 70 06
23
CYLINDER. REPAIR KIT CLUTCH MASTER CYLINDER,5 366604
26
INTERMEDIATE PIECE , Replaced By: A0002950036
29
SCREW
32
ROD CLUTCH PEDAL
35
BRAKE HOSE. HOSE FROM RESERVOIR TO MASTER CYLINDER
38
CLAMP LINE MOUNTING
41
LINE FROM CLUTCH MASTER CYLINDER TO CLUTCH HOSE
44
LINE FROM CLUTCH MASTER CYLINDER TO CLUTCH HOSE
47
PIPE FROM CLUTCH MASTER CYLINDER TO CLUTCH HOSE
47
PIPE FROM CLUTCH MASTER CYLINDER TO CLUTCH HOSE
50
FITTING FROM HYDRAULIC LINE TO CLUTCH SLAVE CYLINDER
56
HOSE FROM HYDRAULIC HOSE TO CLUTCH SLAVE CYLINDER
71
CLAMP ,K 147121, Replaced By: N000000000319
74
PART NAME MISSING SCREW 1/4-20
77
WASHER BRACKET TO CROSS MEMBER, INAPPLICABLE TO BM 685.458-002
80
PART NAME MISSING SPRING WASHER
83
PART NAME MISSING NUT 1/4-20
