Поз.
Артикул
Описание
78
NOZZLE
78
NOZZLE BETWEEN THE LINES 0.8 MM
84
LINE EXHAUST BRAKE, LENGTH AVAILABLE: 3000 MM
84
LINE EXHAUST BRAKE, LENGTH AVAILABLE: 3000 MM
90
PLASTIC PIPE RISING PIPE 4X6 MM
90
PLASTIC PIPE RISING PIPE 4X6 MM
90
PLASTIC PIPE RISING PIPE 4X6 MM
90
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
96
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
102
UNION NUT
108
GLAND , Replaced By: A0019901667
114
SLEEVE LEAK LINE
120
FITTING LINE CONNECTION TO FIRE WALL,5 726664
126
BANJO UNION HOSE WIDTH, / I.D., 4/16 MM
126
BANJO UNION HOSE WIDTH, / I.D., 4/12 MM
132
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
132
CONNECTION FITTING , Replaced By: A0039979172
138
BRAKE HOSE AT CYLINDER, TO BE ADAPTED DURING ASSEMBLY
138
HOSE , Replaced By: A3074290035, +001A0019909871, +001A0029906071
144
CLAMP SENSOR CABLE TO BRACKET
150
SCREW LICENSE PLATE TO BRACKET
150
SCREW , Replaced By: N304017006020
150
SCREW PUMP TO BRACKET
150
SCREW , Replaced By: N304017006016
156
NUT PUMP TO BRACKET
156
NUT , Replaced By: N913004006001
162
FITTING FROM PUMP TO CYLINDER
162
FITTING FROM PUMP TO CYLINDER
162
ELBOW FITTING FROM PUMP TO CYLINDER, Replaced By: N000000006197
168
SCREW CONNECTION 3/2-WAY VALVE BREATHING 8/6 MM
999
PISTONVOSS
999
TS DOUBLE FITTING SOLENOID VALVE
999
BRACKET , Replaced By: A3184920841
999
