Поз.
Артикул
Описание
174
VALVE 3/2-WAY
180
SEAL RINGWABCO
186
SEAL RINGWABCO
192
SEAL RINGWABCO
198
VALVE PARTWABCO
204
WASHER EXHAUST MUFFLER TO STRAP
204
WASHER , Replaced By: N000125008443
210
NUT , Replaced By: N913004008001
216
HOLLOW SCREW HEATING CONNECTION
222
SEAL RING LINE CONNECTION
228
VALVE TWO-WAY VOSS
228
VALVE , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0024299544
234
VALVE BODYTO 002 429 95 44
234
VALVE , Replaced By: A0004291182
240
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
246
O-RING CHECK VALVE TO AIR RESERVOIR
252
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
258
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
264
SEALING RING. SEAL RING DELIVERY LINE TO STEERING
270
FITTING , Replaced By: A6219970872, +001A0009904968
276
FITTING SHUTTLE VALVE
282
FITTING FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "2"
288
ELBOW FITTING DELIVERY LINE TO PUMP
294
T-FITTING SUPPLY LINE FOR TRANSMISSION
300
T-FITTING EXHAUST-BRAKE POWER CYLINDER
306
FITTING FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "20"
306
FITTING FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "20", Replaced By: N000000006191
306
FITTING , Replaced By: A0029971172
312
FITTING AIR RESERVOIR,CONNECTION: "52",K 093236
312
FITTING AIR RESERVOIR,CONNECTION: "52",K 093236, Replaced By: N000000006190
312
FITTING TWO-WAY VALVE,CONNECTION: "12",4 691316
318
FITTING RELAY VALVE,CONNECTION: "10",950459
324
VALVE (3/2-WAY SOLENOID VALVE) WABCO
330
SEAL RINGWABCO
336
VALVE PARTWABCO
342
SEAL RINGWABCO
348
SEAL RINGWABCO
352
BRACKET 3/2-WAY VALVE
358
SCREW PIPE CLAMP
358
SCREW , Replaced By: N304017008021
366
SCREW VALVE TO BRACKET M 8X55
366
SCREW , Replaced By: N304017008043
372
WASHER EXHAUST MUFFLER TO STRAP
372
WASHER , Replaced By: N000125008443
378
NUT , Replaced By: N913004008001
384
FITTING LINE CONNECTION
384
FITTING LINE CONNECTION, Replaced By: N000000006446
390
ELBOW FITTING 3/2-WAY VALVE,CONNECTION: "20",5 765577
396
SEAL RING LINE CONNECTION
402
HOLLOW SCREW HEATING CONNECTION
408
SEAL RING LINE CONNECTION
414
FITTING SHUTTLE VALVE
414
FITTING AIR RESERVOIR,CONNECTION: "52",K 093236
414
FITTING AIR RESERVOIR,CONNECTION: "52",K 093236, Replaced By: N000000006190
420
NUT BRACKET TO SIDE MEMBER
426
RESERVOIR 3/2-WAY VALVE BREATHING
432
NUT FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
438
BRACKET HAND PUMP
438
BRACKET , Replaced By: A3184920841
444
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
444
SCREW , Replaced By: N304017008016
444
SCREW BRACKET TO EXHAUST MUFFLER BRACKET
450
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
450
LOCK WASHER FITTING TO BRACKET
456
NUT COMPRESSED AIR LINE THRU FRAME,5 395034
999
PISTONVOSS
999
TS DOUBLE FITTING SOLENOID VALVE
999
BRACKET , Replaced By: A3184920841
999
